Project In Truth Window Handle-1-1/2"

This window handle features a 1-1/2" hole spacing on centers with a 7/16" lock up dimension. The window handle is constructed of a die cast material that is then powder coated to the finish of your choice. We stock the Bronze color, but other colors are available, call for more information.

Truth 27.31 project in window handle.

Truth Split Arm Operator 15.30

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator. Ships with matching handle.

Left hand shown. Coppertone only, White is no longer available

Common numbers found on this operator is 31850

Common numbers found on the older version of this operator are 40575 for the right hand operator, and 40574 for the left hand operator

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

Left hand shown.

Truth 59.05 Split Arm Operator. This operator is sometimes a replacement for the Wright Split Arm Operator.

White and Gold only

Common number found on this part is 21550
On the Wright Window Operator we might find a 07900 stamped on the arm.

The Truth Encore Handle and Cover are used on the Encore Operators Wi5110 and Wi5010.  The cover are constructed on Plastic and the Handles are die cast metal.  The ones shown on the website are Right Hand and the color is Bronze.  Once color is selected and hand, the different hands will appear, the color is not correct.

Truth Part Numbers 12614 (Left Hand) and 12616 (Right Hand).

Color Chart

Truth 10579 Window Operator Handle

11/32" spline, we some times find the number 45054 stamped on the back side of this handle.

Truth part # 10579.xx where xx is the color code

Truth Maxim Dual Arm Window Operator 50.00-Discontinued in June 2019, we still may have some left, but are shipping the Wi5010, with matching color Flip and Fold Style handle and cover, they are the same operator without the metal cover.

7/31/2019 we are out of the Coppertone, we will be shipping the Wi5010 and matching finish handle and cover.
8/14/2019 we are out of the Bronze, we will be shipping the Wi5010 and matching finish handle and cover.
9/16/2019 we are out of the White, we will be shipping the Wi5010 and matching finish handle and cover.
11/13/2019 we are out the Gold, we will be shipping the Wi5010 and matching finish handle and cover.
4/6/2020 we are out the Beige, we will be shipping the Wi5010 and matching finish handle and cover.
3/17/2021 we are out the Clay, we will be shipping the Wi5010 and matching finish handle and cover.

The Truth 50.00 Maxim Dual Arm is one of the more popular new style operators from Truth. They are only been around since 1999. Also known as a TH-24010, TH-24011, TH-24012, TH-24013, TH-24022, TH-24023, TH-24024, and TH-24025.

Common numbers sometimes found on this operator are 31876, 41011 and 41012.

Truth 51.00 Maxim Awning Window Operator-Discontinued, we do have some stock left, but will be shipping the Wi5110, in its place with matching color cover and handle.

Manufactured since 1999-May 2019. 14-1/2" spread when in the closed position. We sometimes find the numbers 41013 and 41016 stamped on the underside of the 12" long arms. Ships with matching handle.

As of 7-30-2019 we are out of the original 5100's, and will be shipping the Wi5110 with Wi21614 Folding Handle and Cover

Color Chart

The Truth 50.01 Maxim Dual Arm is one of the more popular new style operators from Truth. They are only been around since 1999, but were discontinued in 2020.  The Truth 50.11 is an exact replacement, and it ships with the 12614 or 12616 Encore Handle and Cover.

Common numbers sometimes found on this operator are 31876 and 41011.

Truth 22.21 Single Pull Awning Window Operator

The arms stretch 21-1/2" across in the closed position. The housing is front side mounted with 4 screws. The spacing on the outside screws are 7" on center, and 6" on the inter screws. We find the number 30895 or 30895A stamped on the arm.

The Wi11454 handle in matching color is included with the operator along with the Sash Hook Wi20008.

The Truth Entrygard 10584 Right Hand Bracket measures 2-3/4" x 1-3/8" x 1/2".  The mounting holes are 1-5/8" on center.

The Truth 50.50 Dyad Window Operator was Manufactured from 1999 to 2019. It was also known as a TH-24082, TH-24083, TH-24182, or TH-24183. We are now shipping the Wi5060 as a replacement with matching color Encore Handle and Cover 12614/12616.

We sometimes find the number 31876 stamped on this operator.

The Truth Entrygard 10583 Left Hand Bracket measures 2-3/4" x 1-3/8" x 1/2".  The mounting holes are 1-5/8" on center.

Truth 24.30 Sash Lock

The Truth 24.30 Sash Lock has a hole spacing of 3-13/16" and the locking lug projects 1-3/8"

Truth 11.14 Double Pull Awning Operator.

Attaches to window at two points 9" apart. 25" spread with operator is in closed position. We some times see the numbers 40245, 30897 or 30897A stamped on the arms.

Sash Hooks and matching color handle included.

Truth 16.52 Sash Lock. A very common sash lock that tends to fail because the plastic slide breaks due to incorrect installation at the window manufacturer or being forced when there is a obstruction in the window opening. The new replacement model has a thicker plastic slide. Because the slide is thicker, the keeper, part # Wi41268 and Wi41269 might have to be shimmed with small washers.

Common numbers found on this sash lock are 21328 and 45189

Non handed (can be used on right or left hand windows).

Roto Casement Sash Lock

Housing measures x 4-3/4" tall by x 3/4" wide. The hole spacing is 3-15/16" center to center. The lifting finger projects out 1-1/8"" with the cut out measuring 11-16" deep by 5/16".

Truth Entrygard Dual Arm Operator. We would expect you to find 20810 or 20544 on the linkage arm, which measures 4-7/16" overall length. This is the most common size we find in use. Other common numbers we would expect to find are 31538, 31539, 30841, 30842, 30472, 30470, 20810, or 20544.  Call or email for quantity "Discount Codes".

For offset up, order Wi1510.

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

Part # Hand
WI1561R Right Hand
WI1561L Left Hand

Truth Entrygard Dual Arm Operator

The Truth Encore 51.10 Awning Operator is used on windows that open from the bottom and swing out, like a one piece garage door.  When in the closed position, the arms have an approximate length of 15 inches.  The operator ships with the 31879 detach clip, but does not include the 11647 Maxim Slide Shoe.  The slide shoe is the piece that slides in the track at the bottom of the window.   A common number we find on this operator is 41013.  The housing is constructed of die cast metal, and arms are steel.   The complete assembly is electro statically painted.

Truth Manual Skylight Operator Gear

The gear measures 1-1/16" diameter by 15/16" tall. The hex end is 3/4".

Truth Part # 30742

Truth 15.18 Split Arm Window Operator

Common number found on this operator is 30905, which is found on the linkage arm, along with 45035 on the body, 40351 and 40352 on the arms. Also known as a TH-24174, TH-24175, TH-24176, and TH-24177. Replaces the TH-24018, TH-24019, TH-24020 and TH-24021.

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator. Ships with matching handle.

Left hand shown.

The Truth 14.75 hinge is the most common of the Truth Casement Hinges. The stainless steel track is 10" long, the glide is a plastic coated steel. The most common problem on this hinge is the shoe. When the hinge is installed incorrectly or not maintained the shoe could pull out the window track. Common numbers found on this hinge are 30744B, 31133C, 40942 and 40941.

This Truth hinge is used on the Wi1510, Wi1511, Wi1516, Wi1518, Wi1531, Wi1532, Wi1594 and Wi2301.

This hinge is sold in pairs (one top and one bottom). If your window is the opposite hand, the top hinge goes to the bottom and the bottom hinge goes to the top.

Truth 16.18 Sash Lock.

Dimensions: 2-3/4" x 2-1/4" x 1"
2" between holes

#45098, 40242, 30386 and 31300 are sometimes found stamped inside the housing

Truth 24.31 Sash Lock

Truth 24.31 casement window sash lock.  The hole spacing is 3-13/16" and the "Fork" projects out  1-7/8".   Housing is made of die cast metal that is then powder coated.

Truth Part # 24.31.xx.004

Truth Telescoping Pole Hook Only

Replacement Pole Hook Drive for the Wi10637 for the Truth Telescoping Pole Crank.  The Hook Adapter measures 1" wide, overall length is 2-3/8" including female insert that fits into pole.  The insert spline is 11/32" with a 1/2" diameter.

Truth Part # 10453

Truth Entrygard Dual Arm Window Operator. This operator is the same as the Wi1510, except are arms are made of stainless Steel

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

Common numbers found on this operator are 30758 RH , 30757 LH, 30852, 20812, and 30767

Left hand shown.

Truth Manual Skylight Sprocket Gear

The hex measures 3/4", and made of 1/8" cadmium plated steel. This Gear is what pushes the chain.

Truth Part # 30654

Truth 24.33 Sash Lock

The Truth 24.33 Sash Lock has a hole spacing of 3-13/16" and the locking lug projects 1-5/8"

The Truth 23.49 is a Dyad Operator is rear mounted. The linkage arm is 9-1/4 inches overall length, 8-3/4 inches hole to hole. The rear mounting holes are 5 inches on centers.

Truth 24.23 Casement Locking Handle

This handle features a 2-3/8" center to center hole spacing with a 1/2" lock up.

Truth Part # 24.23.xx.200 , were the xx is the finish code.

Truth 23.02 Window Operator

13-1/2" long arm. Rear Mounting. Ships with matching handle.

Truth 16.16 Sash Lock.

3" x 2-9/16" x 1", with 2-3/8" hole spacing

This sash lock has been discontinued. If you order this part, the 16.27 will be sent as a replacement. According to the factory, the Wi1627 will work as a replacement with any modification.

Used truth keeper # Wi20034

Truth Single Arm Window Operator. This new style replaces the older tradiational size shown in the diagrams.

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

We sometimes find the number 45251 cast on the housing, and 40049 and 40050 stamped on the arms.   This operator has a Nylon Wheel or Roller.

Left hand shown. The Wi11454 handle in matching color is included

Awning Operator Guide Bar 30568

The Truth Operator Guide Bar measures 26-3/4" long with the two mounting holes at 26-1/8" on centers. The bar is constructed of extruded aluminum. The Wi10005 is the component that slides in this track. This track is mounted to the sash.

Truth Part # 30568

Truth 11.44 Awning Operator

Arms are 13-3/8" long, and the span of the arms when in the closed position, arms opposing each other, is 28-1/8" (Hole to Hole)

Awing Operator, we usually find 40759, 40760, and 21221 stamped on the arms, they used to be a cadmium plated steel, now they are powder coated.
