Parts

3/16" Dog (hex) Key, used on Corbin Russwin Exit devices

3/16" Hex Key

2-1/4" overall length

5/32" Dog Key used on old Von Durpin, and Dor-o-Matic exit devices. This key has the longer shaft to fit into the deeper Von Duprin dogging slots.

5/32" hex key

3-1/16" overall length

Yale Trim Spring Blue

Also used on Corbin Russwin and Yale Lever trims. The Blue Spring is for RHR or LH doors. The spring has an outside diameter of 1-1/4".

Yale Part # 60-7000-1224-999
Corbin Russwin # 651F62

Yale Trim Spring Red

Same part as the Corbin Russwin Lever Trim Spring. Used on Yale and Corbin Russwin LHR or RH Doors. The spring has an 1-1/4" diameter.

Yale Part # 60-7000-1225-999
Corbin Russwin # 651F61

Corbin Russwin ED4000/5000 Rim Strike

Standard strike for the ED4200 and ED5200 Rim Panic Devices.

Corbin Russwin part # 650F29

Corbin Russwin ED4000/5000 Series End Cap

Corbin Russwin part # ECK7 or 704F66

Newer impact resistant end cap. Shown in stainless steel.

Corbin Russwin ED4200 Active Head

Used on the Corbin Russwin ED4000 Rim Devices, for non fire rated doors. A non fire rated door is a door were you can use your allen wrench to dog, or lock, the door in the open position during business hours.

Corbin Russwin part # 650F37-8

Corbin Russwin ED5200 Active Head

Used on the Corbin Russwin ED5000 Rim Devices, for non fire rated doors. For fire rated doors, order the G650F36-8. A non fire rated door is a door were you can use your allen wrench to dog, or lock, the door in the open position during business hours.

Corbin Russwin part # 650F35-8

Corbin Russwin ED5200A Active Head

Used on the Corbin Russwin ED5000 Rim Devices, for fire rated doors. For non fire rated doors, order the G650F35-8. A fire rated door is a door were you can NOT use your allen wrench to dog, or lock, the door in the open position during business hours.

Corbin Russwin part # 650F36-8

Corbin Russwin ED6000 Cross Bar Screw

ED6200-3700 Parts Break Down

Corbin Russwin Tenion Sub Assy

Corbin Russwin part #378F74

ED6200-3700 PARTS BREAK DOWN

Corbin Russwin ED8000 Dogging Assembly 491F57

Used on the Corbin Russwin ED8000 Series, ED8200 and ED8400 to lock the Panic Bar in the down, or locked open position. As a side note, we have been told by Corbin Russwin that this dogging assembly is the same one used on the older 9000 Series also.

Corbin Russwin Part # 491F57-8, old number 491F56

Corbin Russwin ED8200 Active Head Assembly

This active head is used on the Corbin Russwin ED8200, Russwin 372, and the Corbin 29 Rim Exit Devices. The springs usually wear or break on this item over years of use.

Corbin Russwin Part # 552F36-8, or the old number 438F40

Corbin Russwin ED8200 Rim Strike

Corbin Russwin part # 386F45

This strike was used on the ED8200, 29, and 372.
