  1. Cal Royal 7000 Alarmed Exit Device

    Cal Royal 7000 Alarmed Exit Device

    Same as the Cal Royal 7700, but with these added features"

    Alarm unit has internal horn. When the push rail is depressed, the horn sounds to provide an audible means of signaling that the door has been opened and violated. The unit has changeable 2 minute alarm cutoff or manual reset. Preset at factory for 2 minute alarm cut off. The key switch to turn alarm off is a standard 1 ¼” cylinder with “C” keyway. The alarm operates on one standard 9 volt transistor battery. When battery is weak the horn will emit an intermittent signal. Alarmed units are supplied with a switch that monitors push rail only. Unit includes “EMERGENCY EXIT ONLY • ALARM WILL SOUND” decal for application on door or unit.

    ALRM7700
    As low as $690.80
  2. Cal Royal 7760 Surface Vertical Rod Exit Device

    Cal Royal 7760 Surface Vertical Rod Exit Device

    For use in institutions, schools, universities, commercial buildings where heavy duty reliable operation is a requirement. ANSI A156.3, Grade 1 heavy duty exit device in surface vertical rod and rim designs. Rail assemblies are heavy duty extruded aluminum body with stainless steel push pad and end caps are made of brass, bronze or stainless steel. Rail travels in direction of the door swing. Trims are thru bolted for additional security. Conforms & Meets ADA Regulations. UL Listed for Panic and ULC10C, UBC 7-2-1777 codes. UL Listed for Fire Exit Hardware.

    Templating matches the Von Dupin 99 and 98

    CR7760EO
    As low as $683.78
  3. Cal Royal 7700 Rim Exit Device

    Cal Royal 7700 Rim Exit Device

    For use in institutions, schools, universities, commercial buildings where heavy duty reliable operation is a requirement. ANSI A156.3, Grade 1 heavy duty exit device in surface vertical rod and rim designs. Rail assemblies are heavy duty extruded aluminum body with stainless steel push pad and end caps are made of brass, bronze or stainless steel. Rail travels in direction of the door swing. Trims are thru bolted for additional security. Conforms & Meets ADA Regulations. UL Listed for Panic and ULC10C, UBC 7-2-1777 codes. UL Listed for Fire Exit Hardware. Uncompromising security and safety in single and double fire exit doors. Chassis mounted unit construction. Rim and vertical rod devices are non-handed and easily reversible. Available in many different functions. Lever and escutcheon trims are grade 1 construction with clutch free-wheeling mechanism. Rose and escutcheon covers 161 cut out.

    Templating matches the Von Dupin 99 and 98

    CR7700EO-
    As low as $522.48
  4. Cal-Royal 9800 Rim Device

    The Cal-Royal 9800 Rim Device is a grade 1 Heavy Duty Exit Device.   The 9800 has the same template as the 8800 and 9800 with escutcheon lever trim. The 36 inch device will be 32 inches wide and can be cut down an additional 2" to fit doors as narrow as 30 inches.  The 48 inch will be 44 inches wide and can be cut down to fit doors 36 inches wide. The device is non handed, meaning it will work on a left hand reverse or right hand reverse door. Strike and mounting screws are included.

    9800EO-
    As low as $376.11
  5. Cal-Royal 9000 Series NESC Lever Trim

    Cal-Royal 9000 Series NESC Lever Trim features hardened steel tailpiece and heavy duty spring to prevent sagging. Standard 6-Pin Schlage C mortise cylinder included. Rigid entrance, key locks or unlocks lever.

    NESC9800-
    As low as $158.36
  6. Cal-Royal 9000 Series Lever Trim HDESC

    Cal-Royal 9000 Series Lever Trim HDESC is for use on the 9800 and 9800 Exit Devices. The Trim has a clutch mechanism to prevent breaking and two heavy duty springs to prevent sagging. Escutcheon measures 2-5/8 inches wide by 10-5/8 inches long.  The lever projects out 2-7/8 inches. Key locks or unlocks lever.

    HDESC-
    As low as $249.09
  7. Cal Royal 2000 Alarmed Exit Device

    Cal Royal 2000 Alarmed Exit Device
    Alarm units has an internal horn. When the push rail is depressed, the horn sounds to provide an audible means of signaling that the door has been opened and violated. The unit has changeable 2 minute alarm cutoff or manual reset. Preset at factory for 2 minute alarm cut off. Jumper cable is provided to swich to continuous alarm. The key switch to turn the alarm off is a standard 1” cylinder with “C” keyway. The alarm operates on one standard 9 volt transistor battery. When battery is weak the horn will emit an intermittent signal. Alarmed units are supplied with two switches. One switch monitors the push rail and the other switch monitors the latch bolt for full proof security.

    Unit includes “EMERGENCY EXIT ONLY. ALARM WILL SOUND” decal for application on door or unit.

    ALM2000
    As low as $306.83
  8. Cal Royal 2000V Exit Device

    Cal Royal 2000V Surface Vertical Rod

    Grade 1
    Non handed-field reversible
    Heavy gauge steel, painted
    4-1/2" minimum stile width

    24" wide x 84" high, and 32" wide and 84" high also available in aluminum only.

    2000V
    As low as $271.76
  9. Cal Royal 2000 Exit Device

    Cal Royal 2000 Series Rim Device

    Grade 1
    Non handed
    3/4" latch bolt throw
    Heavy gauge steel, painted

    Devices available for 32" and 24" wide doors. Please call 1-800-642-2403 for more information

    2000
    As low as $176.56
  10. Cal Royal 2000 Series Exit Device Lever Trim

    Cal Royal 2000 Series Exit Device Lever Trim

    Non-handed Grade 1 (Clutch Style)
    Cylindrical body hardened steel heavy duty tailpiece. For
    1¾” and 2 ¼” doors. Prefix THI before part # for 2 ¼” door
    thickness. Available for fire and non fire rated rim and
    vertical rod exit devices.
    Rose diameter 3 ½”, lever length 4 ¾”.

    ENTOOL-
    As low as $135.29
  11. Cal Royal 4400 Exit Device

    The Cal Royal 4400 Rim Exit Device has a Grade 2 rating. The device features a 3/4" Latchbolt, Roller Strike and a 1" diameter Crossbar. The device comes in a brushed chrome and dark bronze finish, and comes with either a 36" or 48" crossbar. You would need a 4-1/2" minimum stile width.

    CR4400-
    As low as $188.49
  12. Cal Royal Escutcheon 4400 Lever Trim

    The Cal Royal Escutcheon 4400 Lever Trim is non handed (easily field reversible), thru-bolted, rigid non clutch lever for the 4400 Rim Device. The key locks or unlocks the lever. The Escutcheon measures 2-3/4 by 8-1/2 inches, the lever length is 4-3/4 inches.

    ESC44
    As low as $131.50
  13. Cal Royal 4400 Thumbpiece Trim

    The Cal Royal 4400 Thumbpiece Trim is for use on the 4400 Rim Device only. The plate measures 3-1/2 by 16 inches. The key locks or unlocks the thumbpiece. This plate ships with a 6 pin solid brass "C" keyway rim cylinder. And only comes in brushed chrome and dark bronze finishes.

    THP4400-
    As low as $74.05
  14. Cal-Royal 45 Narrow Stile Rim Device

    The Cal-Royal 45 Narrow Stile Rim Device is part of the new 4500 Series.  They are designed for Narrow Stile doors with a minimum of an 1-3/4" stile width.  This is a Grade 1 Exit Device, which is the highest traffic rating possible. Exit device ships with strike and mounting screws.

    Shown is Left Hand Reverse
    Opposite would be Right Hand Reverse

    45-RIM
    As low as $194.66
  15. Cal-Royal 45 Narrow Stile Surface Vertical Rod

    The Cal-Royal 45 Narrow Stile Surface Vertical Rod is part of the new 4500 Series. They are designed for Narrow Stile Doors with a Stile width of at least 1-3/4 inches. The device is rated as a Grade 1, which is the heaviest traffic rating possible. They ship with all mounting hardware and strikes.  This device is non handed and uses a Allen Type dogging system.

    45-SVR
    As low as $315.07
  16. Cal-Royal 4500 Series Lever Trim

    The Cal-Royal 4500 Series Lever Trim is for use on the 45-RIM and 45-SVR Exit Devices. The Lever Trim is non handed and ships with a 6-pin C Keyway Cylinder. The function is Classroom, which means the key will lock or unlock the lever. The lever also incorporates a clutch function so the mechanism will not break when excessive force is applied to the lever.

    ESC45-
    As low as $116.30
  17. Cal Royal CRCODE101 Mechanical Lever Trim for 7700 and 9800 Exits

    The Heavy Duty Cal Royal CRCODE101 is for use on the 7700 and 9800 Rim and Surface Vertical Rods. This lock features Single Code with up to 8000 code combinations, weather resistant, non handed, and code can be changed without removing the lock. Comes in Brushed Chrome finish only.

    Installation and Programming Instructions

    CRCODE101
    $526.75
  18. Cal Royal CRCODE204 Mechanical Lever Lock for 2200, 7700 and 9800 Exits

    The Cal-Royal CRCODE204 is for use with the 2200, 7700 and 9800 Rim and Surface Vertical Rod Devices. The Lever Mechanism features a Break Away Lever, for use with 1-3/4 inch to 2 inch thick doors, non-handed, Single Code User, Key Override, easy on the door code change, weather resistant, and more than 8000 non-sequential possible code combinations.

    Installation and Programming Instructions

    CRCODE204-
    As low as $293.55
  19. Cal Royal 938 Surface Strike

    The Cal Royal 938 Surface Strike is used on the 7700 and 5000 Series Rim Devices.  The strike includes all the mounting screws.

    G938
    $29.22
