Cal-Royal

The Cal Royal 4400 Rim Exit Device has a Grade 2 rating. The device features a 3/4" Latchbolt, Roller Strike and a 1" diameter Crossbar. The device comes in a brushed chrome and dark bronze finish, and comes with either a 36" or 48" crossbar. You would need a 4-1/2" minimum stile width.

The Cal-Royal 221 Bottom Strike is used on the 2000, 5000, 7000 and 9000 Panic Bars with Surface Vertical Rods.

The Cal Royal 239 Rim Strike is used on the 9800 and 2200 Rim Devices.  The Strike is Nylon Black Coated.

The Cal Royal TAIL1 is an extender for the ENTOOL Lever Trim.  The extender works on doors up to 2-1/4 inches thick.  The TAIL1 includes two longer screws, two set screws (not shown), allen wrench, and hub adaptor.

The Cal Royal GLS7700 Rim Device is for use on Aluminum Framed Glass Doors when the Stile width is 1-3/4 inch or more.  The exit device ships with wood and machine screws, along with the Strike plate.  The stainless steel latch bolt has a 3/4 inch throw. This device is a Grade 1, which is the heaviest duty rating.

The Cal Royal GLSRIM9800 is an Entrance Function Lever Handle for the GLS7700 and GLS9800 Narrow Stile Rim Exits.  The Base measures 1-3/4 inches wide by 8 inch tall, with a 2-3/8 inch thick base.

Drawer Pull 3" Centers Stainless Steel. stainless steel wire pull is 3-1/4" wide x 1-1/4" projection. 8-32 Screws are included.

The Cal-Royal 9800 Rim Device is a grade 1 Heavy Duty Exit Device.   The 9800 has the same template as the 8800 and 9800 with escutcheon lever trim. The 36 inch device will be 32 inches wide and can be cut down an additional 2" to fit doors as narrow as 30 inches.  The 48 inch will be 44 inches wide and can be cut down to fit doors 36 inches wide. The device is non handed, meaning it will work on a left hand reverse or right hand reverse door. Strike and mounting screws are included.

The Cal-Royal 9860 is a Grade 1 Surface Mounted Vertical Rod Exit Device.

Cal-Royal 9000 Series NESC Lever Trim features hardened steel tailpiece and heavy duty spring to prevent sagging. Standard 6-Pin Schlage C mortise cylinder included. Rigid entrance, key locks or unlocks lever.

Cal-Royal 9000 Series Lever Trim HDESC is for use on the 9800 and 9800 Exit Devices. The Trim has a clutch mechanism to prevent breaking and two heavy duty springs to prevent sagging. Escutcheon measures 2-5/8 inches wide by 10-5/8 inches long.  The lever projects out 2-7/8 inches. Key locks or unlocks lever.

Drawer Pull 3-1/2" Centers Stainless Steel, stainless steel wire pull. Measurements are 3-3/4" wide x 1-1/4" projection and the 8-32 screws are included.

Replacement End Cap and Bracket for the Cal-Royal 2200 Rim and Vertical Rod Exit Devices

Drawer Pull 4" Centers Stainless Steel. Stainless steel wire pull with the measurement 4-1/4" wide x 1-1/4" projection. The 8-32 screws are included.

The Cal Royal Escutcheon 4400 Lever Trim is non handed (easily field reversible), thru-bolted, rigid non clutch lever for the 4400 Rim Device. The key locks or unlocks the lever. The Escutcheon measures 2-3/4 by 8-1/2 inches, the lever length is 4-3/4 inches.

The Cal Royal 4400 Thumbpiece Trim is for use on the 4400 Rim Device only. The plate measures 3-1/2 by 16 inches. The key locks or unlocks the thumbpiece. This plate ships with a 6 pin solid brass "C" keyway rim cylinder. And only comes in brushed chrome and dark bronze finishes.

The Cal-Royal 45 Narrow Stile Rim Device is part of the new 4500 Series.  They are designed for Narrow Stile doors with a minimum of an 1-3/4" stile width.  This is a Grade 1 Exit Device, which is the highest traffic rating possible. Exit device ships with strike and mounting screws.

Shown is Left Hand Reverse
Opposite would be Right Hand Reverse

The Cal-Royal 45 Narrow Stile Surface Vertical Rod is part of the new 4500 Series. They are designed for Narrow Stile Doors with a Stile width of at least 1-3/4 inches. The device is rated as a Grade 1, which is the heaviest traffic rating possible. They ship with all mounting hardware and strikes.  This device is non handed and uses a Allen Type dogging system.

The Cal-Royal 4500 Series Lever Trim is for use on the 45-RIM and 45-SVR Exit Devices. The Lever Trim is non handed and ships with a 6-pin C Keyway Cylinder. The function is Classroom, which means the key will lock or unlock the lever. The lever also incorporates a clutch function so the mechanism will not break when excessive force is applied to the lever.

The Heavy Duty Cal Royal CRCODE101 is for use on the 7700 and 9800 Rim and Surface Vertical Rods. This lock features Single Code with up to 8000 code combinations, weather resistant, non handed, and code can be changed without removing the lock. Comes in Brushed Chrome finish only.

Installation and Programming Instructions

The Cal-Royal CRCODE204 is for use with the 2200, 7700 and 9800 Rim and Surface Vertical Rod Devices. The Lever Mechanism features a Break Away Lever, for use with 1-3/4 inch to 2 inch thick doors, non-handed, Single Code User, Key Override, easy on the door code change, weather resistant, and more than 8000 non-sequential possible code combinations.

Installation and Programming Instructions

Engraved Push Plate-Stainless Steel

16 gauge (.050") brushed stainless steel push plate with black engraved 3/4" high  "PUSH".  Available in two sizes 3-1/2" x 15" and 4" x 16".   Only available in Brushed Stainless Steel.

The Cal Royal 938 Surface Strike is used on the 7700 and 5000 Series Rim Devices.  The strike includes all the mounting screws.

Replacement Cal-Royal 7000 Series End Caps.

Replacement Cal-Royal 9800 End Cap and Bracket.   Includes mounting screws.

Cal Royal 300 Series Door Closer
Adjustable for sizes 3-6 or Barrier Free sizes 1-4
3/4" x 9-1/16" hole spacing
5 Year Warranty

Cal Royal 300 Series Catalogue

Cal Royal 400 Series Door Closer

Adjustable closing and latcting speeds
Powder Coated Painted Finishes
5 year warranty

Size 420 3/4" x 6-5/8" hole spacing
Size SM 430P 3/4" x 6-1/2" hole spacing
Size 430P 3/4" x 8-3/16" hole spacing
Size 440P 3/4" x 8-3/16" hole spacing

Cal Royal 400 Series Catalogue

Cal Royal 700 Series Door Closer

Adjustable closing and latching speeds
3/4" x8-3/16" for sizes 2 and 3, and 3/4 x 9-1/16" for size 4 holes spacing
Powder Coated Painted Finishes
5 year warranty

Cal Royal 800 Door Closer

CAL-ROYAL’S FINEST DOOR CLOSER SERIES
MEETING THE HIGHEST INDUSTRY STANDARDS, GRADE 1
HEAVY-DUTY DOUBLE LEVER ARM WITH EXTRA SMOOTH
ACTION FULL FEATURE MULTI-SIZE COMMERCIAL DOOR
CLOSER FOR USE IN OFFICE BUILDINGS, SHOPPING
CENTERS AND OTHER COMMERCIAL

CR801S - SLIM COVER

CR801 - FULL COVER

Please allow one week lead time

Cal Royal 900 Series Door Closer

Pull or Push side, or Top Jamb mounting, Meduim Duty Door Closer, Powder Coated Painted Finishes, 5 year warranty

3/4" x 11-1/8" cylinder hole spacing

Cal Royal 900 Series Catalogue

Cal Royal Door Closer CR440
Uses the same templating as the LCN 4040
Door Closer with substantial savings.
Part # CR4040

Cal Royal CR4040 Catalogue

Cal Royal 2000 Alarmed Exit Device
Alarm units has an internal horn. When the push rail is depressed, the horn sounds to provide an audible means of signaling that the door has been opened and violated. The unit has changeable 2 minute alarm cutoff or manual reset. Preset at factory for 2 minute alarm cut off. Jumper cable is provided to swich to continuous alarm. The key switch to turn the alarm off is a standard 1” cylinder with “C” keyway. The alarm operates on one standard 9 volt transistor battery. When battery is weak the horn will emit an intermittent signal. Alarmed units are supplied with two switches. One switch monitors the push rail and the other switch monitors the latch bolt for full proof security.

Unit includes “EMERGENCY EXIT ONLY. ALARM WILL SOUND” decal for application on door or unit.

Cal Royal 2000 Series Rim Device

Grade 1
Non handed
3/4" latch bolt throw
Heavy gauge steel, painted

Devices available for 32" and 24" wide doors. Please call 1-800-642-2403 for more information

Cal Royal 2000V Surface Vertical Rod

Grade 1
Non handed-field reversible
Heavy gauge steel, painted
4-1/2" minimum stile width

24" wide x 84" high, and 32" wide and 84" high also available in aluminum only.

Cal Royal 2200 Escutcheon Lever Trim

2-5/16" X 8-1/2"

Cal Royal 2000 Series Thumb Pc Trim

2-5/8" X 16"

Cal Royal part # THP00
