Windows| Truth

Truth Encore Single Arm Operator.

Truth Encore Dual Arm Operator for Low Profile windows.  Same as the Wi5010, but has a rectangular slide on the long arm instead of the standard models square slide.

The Truth 50.60 Encore Dyad Operator has been in production since about 1999.   In the beginning Truth offered the Maxim and the Encore Systems.   The Maxim is being phased out and the Encore is the only one made now.   The Encore will replace all of the Maxim operators, and have the same hole spacings and operation, but they have the interchangeable handle and covers.

The Operator in the Picture is a Left Hand.

Window Operator Handing

Truth 11" Surface Rear Mounted Operator

This Truth Surface Mounted Window Operator is usually used on commercial aluminum windows. It features an 11" long arm, measured from the center of the housing to the center of the metal roller.

The Truth-Wright Split Arm Operator is a replacement for the older Wright Operators.  Linkage arm has an overall length of 3-5/8".

Left Hand Shown in Picture, we can only get these in white.

The Truth Encore Handle and Cover are used on the Encore Operators Wi5110 and Wi5010.  The cover are constructed on Plastic and the Handles are die cast metal.  The ones shown on the website are Right Hand and the color is Bronze.  Once color is selected and hand, the different hands will appear, the color is not correct.

Truth Part Numbers 12614 (Left Hand) and 12616 (Right Hand).

Color Chart

Angle Base 1-3/8" Window Handle Truth

Also known as the Truth 25.39, this handle is constructed of a die cast metal and powder coated to the desired color. The distance between the screws is 1-3/8" on center. The handle measures 3-3/4" long, base measures 2-1/8" long. The number found on the handle is 45086 for the Right Hand, and 45085 for the Left Hand. We also find U.S. Pat. # 4,930,820

Right Hand is shown in picture.

Truth 16.27 Sash Lock. Sometimes known as the Truth Entrygard Sash Lock.

3" high x 2-9/16" deep x 1" thick.  We sometimes find the numbers 45208 or 40707 cast into this part.

Left hand sash lock shown in picture.

2-3/8" between screws

The Truth 50.01 Maxim Dual Arm is one of the more popular new style operators from Truth. They are only been around since 1999, but were discontinued in 2020.  The Truth 50.11 is an exact replacement, and it ships with the 12614 or 12616 Encore Handle and Cover.

Common numbers sometimes found on this operator are 31876 and 41011.

The Truth 50.50 Dyad Window Operator was Manufactured from 1999 to 2019. It was also known as a TH-24082, TH-24083, TH-24182, or TH-24183. We are now shipping the Wi5060 as a replacement with matching color Encore Handle and Cover 12614/12616.

We sometimes find the number 31876 stamped on this operator.

Truth 52.01 Maxim Single Arm Window Operator. Manufactured since 1999. Ships with matching handle.

Truth Maxim Dual Arm Window Operator 50.00-Discontinued in June 2019, we still may have some left, but are shipping the Wi5010, with matching color Flip and Fold Style handle and cover, they are the same operator without the metal cover.

7/31/2019 we are out of the Coppertone, we will be shipping the Wi5010 and matching finish handle and cover.
8/14/2019 we are out of the Bronze, we will be shipping the Wi5010 and matching finish handle and cover.
9/16/2019 we are out of the White, we will be shipping the Wi5010 and matching finish handle and cover.
11/13/2019 we are out the Gold, we will be shipping the Wi5010 and matching finish handle and cover.
4/6/2020 we are out the Beige, we will be shipping the Wi5010 and matching finish handle and cover.
3/17/2021 we are out the Clay, we will be shipping the Wi5010 and matching finish handle and cover.

The Truth 50.00 Maxim Dual Arm is one of the more popular new style operators from Truth. They are only been around since 1999. Also known as a TH-24010, TH-24011, TH-24012, TH-24013, TH-24022, TH-24023, TH-24024, and TH-24025.

Common numbers sometimes found on this operator are 31876, 41011 and 41012.

Truth Entrygard Dyad Window Operator.

Common numbers found on this operator are 30636, 30637, and 20544 for the old style,
31368, 20810, and 45275 for the new style.  Call or email for quantity "Discount Codes".

For link off-set up version order Wi1562

See attached file of what the Original Version looked like

Left hand shown.

Truth 15.62 Dyad Casement Operator. The 15.62 is no longer manufactured, we can not get the Right Hand anymore, but have a decent supply of Left Hand's.

Same as the Wi1511, but linkage arm is off set up

Linkage arm stamped 20810A, gear stamped 31367L, base stamped 45108

Truth Entrygard Dual Arm Window Operator. This operator is the same as the Wi1510, except are arms are made of stainless Steel

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

Common numbers found on this operator are 30758 RH , 30757 LH, 30852, 20812, and 30767

Left hand shown.

Truth Entrygard Dual Arm Operator. We would expect you to find 20748 on the linkage arm, which measures 2-7/8" overall length. Other common numbers we would expect to find are 31538, 31539, 30841, 30842, 30472, 30470, and 20748.  Call or email for quantity "Discount Codes".

2-7/8" linkage dimension, off set up.

Order Wi1516 if your link dimension is 3-3/4" stamped 20755.
Order Wi1510 if your link dimension is 4-7/16" stamped 20810.

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

Left hand shown.

Part # Hand
WI1515R Right Hand
WI1515L Left Hand

Truth Entrygard Casement Operator

Truth Entrygard Dual Arm Operator. We would expect you to find 20755 on the bottom of the linkage arm, which measures 3-3/4" overall length. Other common numbers we would expect to find are 31538, 31539, 30841, 30842, 30472, 30470, and 20755.  Call or email for quantity "Discount Codes".

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

3-3/4" link dimension, offset down. For offset up order Wi1516

Order Wi1510 if your link dimension is 4-7/16" stamped 20810.
Order Wi1515 if your link dimension is 2-7/8" stamped 20748.

Left hand shown.

Truth Entrygard Dual Arm Operator. We would expect you to find 20755 on the linkage arm, which measures 3-3/4" overall length. Other common numbers we would expect to find are 31538, 31539, 30841, 30842, 30472, 30470, and 20755.  Call or email for quantity "Discount Codes".

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

3-3/4" link dimension, offset up. For offset down order Wi1520

Order Wi1510 if your link dimension is 4-7/16" stamped 20810.
Order Wi1515 if your link dimension is 2-7/8" stamped 20748.

Left hand shown.

PART # HAND
WI1516R RIGHT HAND
WI1516L LEFT HAND

Truth Entrygard Dual Arm Operator

Truth Entrygard Dual Arm Operator. We would expect you to find 20810 or 20544 on the linkage arm, which measures 4-7/16" overall length. This is the most common size we find in use. Other common numbers we would expect to find are 31538, 31539, 30841, 30842, 30472, 30470, 20810, or 20544.  Call or email for quantity "Discount Codes".

For offset up, order Wi1510.

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

Part # Hand
WI1561R Right Hand
WI1561L Left Hand

Truth Entrygard Dual Arm Operator

Truth Window Operator Surface Mount 11"

This Truth Surface Mounted Window Operator is usually used on commercial aluminum windows. It features an 11" long arm, measured from the center of the housing to the center of the metal roller. The outside mounting screw holes are 4-3/4" a part and the inter screws are 3-7/8" on center.

Right Hand Shown, in Aluminum

Right Hand Aluminum Wi36223AL
Left Hand Aluminum Wi36222AL
Right Hand Bronze Wi36223BR
Left Hand Bronze Wi36222BR
Right Hand White Wi36223W
Left Hand White Wi36222W

Truth Maxim Dual Arm Window Operator 50.10

The Truth 50.10 Maxim Dual Arm is one of the more popular new style operators. This operator is the same as the 50.00, but without the painted steel cover riveted to it. Some numbers we find on this operator are 41011 and 31876.

Left Hand Operator shown in picture.

Truth 24.89 Multi Point Locking System Sash Lock

31149 is stamped on the Right Hand Sash Lock

31369 is stamped on the Left Hand Sash Lock

Truth Multi Point Locking System sash lock. The hole spacing on the lock is 3-7/16"

Common numbers found on this lock is 31401 and 31402

Truth 16.16 Sash Lock.

3" x 2-9/16" x 1", with 2-3/8" hole spacing

This sash lock has been discontinued. If you order this part, the 16.27 will be sent as a replacement. According to the factory, the Wi1627 will work as a replacement with any modification.

Used truth keeper # Wi20034

Truth Two Hole 1-1/2" Window Handle

Truth 25.31 Two Hole Cam Handle die cast construction with a powder coated painted finish. We find the numbers 45086 on the right hand handles, and 45085 on the left hand handles.

Right Hand shown in picture.

Truth Hole Two 1-1/2" Window Handle

Truth 25.29 Two Hole Window Handle die cast construction with a powder coated painted finish. We find the numbers 45086 on the right hand handles, and 45085 on the left hand handles.  Right Hand shown on Website!

Project In Truth-1-1/2"- 1/2" Lock Up

This window handle features a 1-1/2" hole spacing on centers with a 1/2" lock up dimension. The window handle is constructed of a die cast material that is then powder coated to the finish of your choice. We stock the Bronze color, but other colors are available, call for more information.

Truth 27.32 project in window handle.

Project In Truth Window Handle-1-1/2"

This window handle features a 1-1/2" hole spacing on centers with a 7/16" lock up dimension. The window handle is constructed of a die cast material that is then powder coated to the finish of your choice. We stock the Bronze color, but other colors are available, call for more information.

Truth 27.31 project in window handle.

Truth 59.05 Split Arm Operator. This operator is sometimes a replacement for the Wright Split Arm Operator.

White and Gold only

Common number found on this part is 21550
On the Wright Window Operator we might find a 07900 stamped on the arm.

Truth 23.54 Split Arm Window Operator

A common number found on this operator is 30866

4-1/2" long linkage arm, Ships with matching handle.

Truth Split Arm Operator.

White and Bronze only. Ships with matching handle.

Common numbers found on this operator is 30866

Truth 23.03 Single Arm Operator

13-1/2" Arm length, Front Mounting, Ships with matching handle.

Truth 23.02 Window Operator

13-1/2" long arm. Rear Mounting. Ships with matching handle.
