Hadrian Corner Bathroom Stalls in Powder Coated Steel. Also known as Baked Enamel Partitions. Overhead braced floor mounted stalls. Standard stalls are 36"x 60" depth (with 24" door), ADA stalls are 60"x60" depth (ADA with 36" door). All brackets, door kits, headrails and brackets are included to install properly. Doors can be either an in or out swing. Up to 8 standard stalls total or 7 standard and 1 ada stall. All toilet partitions ship in 48-72 hours plus 2-4 days travel. To have an ADA stall you must select 1 ADA 24x60, plus 1 standard stall for 1 complete 60x60 ada stall. To have an ADA stall & standard stall, you must select 2 standard stalls and 1 ADA stall 24x60. All quick ship colors are marked on the color chart with an American flag. The color choices have double stars on them for quick ship when ordering. Any other color is 3 weeks out for delivery.

Hadrian Color Chart

Hadrian Instructions Powder Coated

Hadrian Free Standing Stalls in Powder Coated Steel. Also known as Baked Enamel Partitions. Overhead braced floor mounted stalls. Standard stalls are 36"x 60" depth (with 24" door), ADA stalls are 60"x60" depth (ADA with 36" door). All brackets, door kits, headrails and brackets are included to install properly. Doors can be either an in or out swing. Up to 8 standard stalls total or 7 standard and 1 ada stall. All toilet partitions ship in 48-72 hours plus 2-4 days travel. To have an ADA stall you must select 1 ADA 24x60, plus 1 standard stall for 1 complete 60x60 ada stall. To have an ADA stall & standard stall, you must select 2 standard stalls and 1 ADA stall 24x60. All quick ship colors are marked on the color chart with an American flag. The color choices have double stars on them for quick ship when ordering. Any other color is 3 weeks out for delivery.

Hadrian Color Chart

Hadrian Instructions Powder Coated

Hadrian Partitions Aluminum Headrail for 1" thick material Type A used on overhead braced floor mounted Solid Plastic Partitions. The headrail goes over the top of the pilaster which is 1" for the headrail to fit over the top of the pilaster. The slot is for 1/4" curtain hook. The headrail bolts to the pilaster for stability at the top. Overall dimension is 1-1/4"x1-3/4"ht. Also known as part number 620060, 620074.

Also known as Part# 9HR60SP, 9HR74SP and 9HR96SP.

The Stainless Stel Indicator Latch and Keeper are designed to work with for 1" doors and 1-1/4" pilasters thickness. Constructed of stainless steel with a brushed finish. Comes fasteners for installation. Known as manufacturers part numbers 905200,910128 and 910129.

The Matte Black Hadrian 1/2" Pedestal Support Brace is constructed of stainless steel. Pedestal support brace is used in place of a traditional pilaster where the pilaster anchors to the ground. This pedestal support brace allows pilasters to be off the ground but still provide structure to partitions. Designed to be used under a pilaster or panel that is 1/2" thickness. Available in 12", 9" and 4" heights and comes with fasteners for installing. Known as manufacturers part number 673441-12AF-BLK, 673441-9AF-BLK and 673441-4AF-BLK.

Hadrian Between Wall Stalls in Powder Coated Steel. Also known as Baked Enamel Partitions. Overhead braced floor mounted stalls. Standard stalls are 36"x 60" depth (with 24" door), ADA stalls are 60"x60" depth (ADA with 36" door). All brackets, door kits, headrails and brackets are included to install properly. Doors can be either an in or out swing. Up to 8 standard stalls total or 7 standard and 1 ada stall. All toilet partitions ship in 48-72 hours plus 2-4 days travel. To have an ADA stall you must select 1 ADA 24x60, plus 1 standard stall for 1 complete 60x60 ada stall. To have an ADA stall & standard stall, you must select 2 standard stalls and 1 ADA stall 24x60. All quick ship colors are marked on the color chart with an American flag. The color choices have double stars on them for quick ship when ordering. Any other color is 3 weeks out for delivery.

Hadrian Color Chart

Hadrian Instructions Powder Coated

Hadrian Aluminum Headrails for 1"X60" Type A used on overhead braced floor mounted partitions. For Hadrian Powder Coated Steel and Stainless Steel Partitions. The headrail goes between a U shape which is 1" for the headrail to fit into at the top of the pilaster, the headrail bolts to the pilaster for stability at the top. Also known as part number 580060.

Hadrian Aluminum Headrails for 1"X74" Type A used on overhead braced floor mounted partitions. For Hadrian Powder Coated Steel and Stainless Steel Partitions. The headrail goes between a U shape which is 1" for the headrail to fit into at the top of the pilaster, the headrail bolts to the pilaster for stability at the top. Also known as part number 580074.

Hadrian Aluminum Headrails for 1"X96" Type A used on overhead braced floor mounted partitions. For Hadrian Powder Coated Steel and Stainless Steel Partitions. The headrail goes between a U shape which is 1" for the headrail to fit into at the top of the pilaster, the headrail bolts to the pilaster for stability at the top. Also known as part number 580096.

Uses toggle & screw not included.

Uses toggle & screw not included.

Cast S.S. Slide Bolt Latch 5/8" Bar To Door, 3-1/2" Between Screws. Cast stainless steel construction. Base is 4-1/2" tall with a hole spacing of 3-1/2" on center. Latch bolt is 3-3/32" long by 1" wide by 3/16" thick and has a throw of 15/16". The latch projects out 1-9/16". The distance from the back of the base to the underside of the latch bolt is 9/16". Also known as a Bathroom Stall Slide Latch and Toilet Partition Locks. Manufacture part #5053. Shipped with screws. Used by accurate and global.

Hadrian toilet Partition Metal Alcove Stalls in Powder Coated Steel overhead braced floor mounted compartments. The alcove stall includes 36" door, 2 pilasters and panel to make up the distance. Hadrian Partition Doors can be either in or out swing. All partition hardware included with standard chrome hardware for the door kits and brackets. Quick ship toilet partitions ship in 48-72 hours plus 2-3 day travel. All quick ship colors are marked on the color chart with an American flag. The color choices have double stars on them for quick ship when ordering. Any other color is 3 weeks out for delivery.

Hadrian Color Chart

Hadrian Instructions Powder Coated

Hadrian Alcove Channel Instruction

Hadrian Partitions Slide Bolt Latch Chrome Plated

Zamac die cast construction, polished chrome finish. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5020.

Shipped with mounting screws.

The Matte Black Indicator Latch and Keeper are designed to work with doors and pilasters that are 3/4" thickness. Constructed of zamac metal with a matte black finish. Comes fasteners for installation. Known as manufacturers part numbers 671600-BLK and 671601-BLK.

The Matte Black Hadrian Continuous L Bracket is constructed of stainless steel and measures 1-1/2"Wx1-1/4"Hx57-1/2"L. These are not designed to be through bolted together. Designed to be mounted on the inside of a partitions stall so hardware is not visible from the outside. Bracket comes with fasteners to install. Known as manufacturers part number H60358-BLK.

The Matte Black Hadrian L Bracket is constructed of stainless steel and measures 1-1/2"Wx1-1/4"Hx2-1/2"L. It is recommended that 3 bracket be used for panels of 58" height. These are not designed to be through bolted together. Designed to be mounted on the inside of a partitions stall so hardware is not visible from the outside. Bracket comes with fasteners to install. Known as manufacturers part number 673411-BLK.

The Matte Black Hadrian Two Ear Bracket is constructed of stainless steel and measures 3-1/8"Wx1-1/4"Hx3-1/8"L. This two ear bracket is designed for 1/2" thickness material. It is recommended that 3 bracket be used for panels of 58" height. Can be used on partitions or urinal screens. Bracket comes with fasteners to install. Known as manufacturers part number 672115-BLK.

The Matte Black Hadrian Two Ear Bracket is constructed of stainless steel and measures 3-1/8"Wx1-1/4"Hx47"L. This two ear bracket is designed for 1/2" thickness material. Bracket comes with fasteners to install. Known as manufacturers part number H20559-BLK.

Replaces old style hinge pin. If you have old style you must buy upper hinge too. 631400 new, used with 9hh350, 9hh300, 9hh550, 9hh500 used with arch also. This product uses a phillips head screwdriver, old style was a torx head. The dimensions are 3/8" diameter by 1-1/2" height.

The Matte Black Hadrian Continuous U Bracket is constructed of stainless steel. This continuous U bracket is designed for 1/2" thickness material and measures 57-1/2" in length. Bracket comes with fasteners to install. Known as manufacturers part number H60258-BLK.

The Matte Black Hadrian Corner Headrail Kit is designed for mounting Hadrian Matte Black Headrails. Constructed of stainless steel with matte black finish. Sping clip and end cap are made of plastic. This kits includes (2) Wall Brackets, (1) Spring Clip, (1) L Bracket, (1) Headrail Endcap and fasterners. Would be used for partitions that need headrail across front of partitions as well as down one side. Spring clips would be used if you are needing to join two headrails together. L bracket is used to attach Headrail on the side of partitions to back wall. Known as manufacturers part number 675411-BLK.

The Matte Black Hadrian Alcove Channel is constructed of anodized aluminum. One side of the channel is for 1/2" thickness and the other is 3/4" thickness. This alcove channel is used to connect a panel and pilaster in-line with different thicknesses. The alcove channel is 57-1/2" in length and comes with fasteners to install. Known as manufacturers part number H60158-BLK.

Toilet partition Alcove Channel for Powder Coated Steel or Stainless Steel partitions. Constructed of extruded aluminum with #4 brushed finish(similar to stainless steel). Typically used with new construction but can be used on existing partitions. Designed to join a Pilaster and Panel in-line to eliminate sightline gaps to provide additional privacy. The indented rounded curve is where the Pilaster(1-1/4" Thickness) will attach, while the open end of channel is where the panel(1" Thickness) with attach. Comes with screws for attaching to pilaster and panel. Alcove channel is not pre-drilled so you will have the flexibility to place screws where needed. Provides the ability to space the panel inside the alcove channel as close as 1/4" to about 3/4". The Alcove Channels are for Hadrian's Standard(58" Ht Panels), Elite(64" Ht Panels) and Elite Plus(72" Ht Panels) Series of restroom partitions. Could be used on different manufacturers partitions as well. Manufactuered by Hadrian Partitions, known as 560157-990, 560170-900 and 560172-900.

Hadrian Headrail Retrun Kit is designed to work with Hadrians Metal Stall Partitions. The headrail retun kit will work with 1-1/4" thickness headrails from Hadrian. Designed to work with powder coated steel and stainless steel stalls. This kit includes Brackets,Wall Anchoring Screws, Plastic Anchors, Fastening Screws and Headrail End Cap. Can be used to run across the top of partitions either between two wall or runnning from a rear wall to a pilaster. Often used in conjuction with Hadrian Headrail (60")9HR60A, (74")9HR74A and (96")9HR96A.

Manufacturer Part# 607200.

Hadrian Headrail End Plug for Metal and Stainless Steel Partitions. This is used to close off the end of the partition headrail at the top of your partitions. This goes over the 1"x1-5/8"ht outside edge of headrail opening. Known as part number 607220 and used only with Hadrian Partition Company.
