Latch finger 701730 & 786540 included, uses 853715 recess lifter.
7119174, LR130R.

This is the same trusted Von Duprin 99 with Electric Latch Retraction, also known as EL.

The EL feature allows for the remote unlatching of exit devices. A control station operator can flip a switch to retract the latch bolt and immediately change an exit door to push-pull operation. A powerful, continuous duty solenoid retracts the latch bolt, either for momentary unlatching, or for extended periods of time. The EL feature is an alternative to manual dogging.

The rim device is non-handed.
A power supply is required for operation, see related products.
Ships with all the mounting screws and the 299 Strike.

Republic Steel st 72" Lock Bar-59-7/8" Length, Latch finger 701730 included, uses 700308-700309 handle assembly.

International Door Closer 854 Series

FEATURES
Two Adjustment Valves: Closing and Latching speeds controlled by separate regulating Valves, Universal application Non-handed for standard top
jamb or parallel arm installation.

Ships with regular arm and parallel arm bracket.

3/4" x 9-1/16" mounting holes

Dor-o-Matic 1790 NL/HB Cylinder Assembly. Converts a 1790EO to the Night Latch or Hold Back function

Doromatic Part # CYLASY.1151 or 179CA

1790 parts breakdown

Adams Rite 8700 / 8800 Mounting Base Kit

Replacement active head for the Adams Rite 8800 and Adams Rite 8700 Star Wheel Latching System.   Kit includes replacement rivets to reattach.

Adams Rite Part # 91-8800

LCN 4010 Fusible Link Door Closer

Standard 4010 series closer is shipped with fusible link arm, standard plastic cover, and self reaming and tapping screws. Sized cylinders for interior doors to 5’0” and exterior doors to 4’0”. Non-sized cylinder (4011) adjustable for interior doors to 4’6” and exterior doors to 3’6”. Fusible link melts at 120 degrees and allows the door to close. Closer mounts hinge side, specify right or left swinging door. 4011 cylinder meets ADA requirements.

We ship the 4011 FL

Acorn Sweep Lock 2-1/4"

This sweep latch has a hole spaceing of 2-1/4" between screws. Also known as a Window Lock or Double Hung Window Lock. Acorn Sweep Lock.

White only

Mills Toilet Partition Keeper Bumper For Concealed Latches 1-1/4" Round Edge Post

Polished chrome plate Zamac die casting construction. Strike and Keeper measures 1-1/4" high by 2-3/8" wide by 1-3/4" deep. Stop is 1/2" thick and projects out 1-1/8". The latching slot is 7/16" deep x 3/4" high. This Bathroom Toilet Door Keeper is designed for use on 1-1/4" thick round edge posts or pilasters. Also known as a Bathroom Stall Strike and Keeper for Inswing/Outswing 1-1/4". Manufacture part # 5590.

Shipped with mounting screws.

American Exit Device 60 Series Dogging Assembly

This is the assembly that keeps the latch bolt retracted when the hex key is tightened. This dogging assembly is also used on the Dorma 8000 Series devices.

Von Durpin 8827F Plunger Release Bracket

Used with the Fire Rated 8827 Top Latch.

Von Duprin  # 107765

LCN 4110 Fusible Link Door Closer

Standard 4110 series closer shipped with Fusible Link arm, standard plastic cover, 4110-201 FIFTH SCREW SPACER and self reaming and tapping screws. Sized cylinders adjustable for interior doors to 5’0” and exterior doors to 4’0”. Non-sized cylinder adjustable for interior doors to 4’6” and exterior doors to 3’6”. Closer mounts parallel arm, specify right or left swinging door. 4111 cylinder meets ADA requirements.

We ship the 4111 FL

Republic Steel upper locking bar for a two person locker. 700337 spring and 700338 latch included. 7-5/8" length. Prior to current. Facing the locker the hinges will be on the Left side. Also known as 75803, 2790, 70009, rs1124, lr803.

Republic Steel upper locking bar for a two person locker RH. 700337 spring and 700338 latch included. 7-5/8" length. Prior to current. Facing the locker the hinges will be on the Right side. Also known as 75703, 2719, 70010, rs1123, lr703.

Von Duprin 8827 Bottom Rod Connector.

Connects bottom rod to the bottom latch. The Bottom Rod Connector is included with the Von Durpin Bottom Rod.

Von Duprin Part # 050327
Old Part #960578

Sargent Exit Device 90 Series Mouse Trap Spring

Used on the Sargent 9898 Rim Device on the opposite side of the case as the latch bolt.

Sargent part # 98-2159

International Door Closer 853 Series
FEATURES

Two Adjustment Valves: Closing and Latching speeds controlled by separate regulating Valves,

Universal application Non-handed for standard top jamb or parallel arm installation. Ships with regular arm and parallel arm bracket.

Direct replacement for the older style Norton 1602 and 1603, and Yale 52 and 53

3/4" x 8-3/16" mounting holes

Standard 4110 series closer shipped with HOLD OPEN CUSH N STOP arm, standard plastic cover, 4110-201 FIFTH SCREW SPACER and self reaming and tapping screws. Sized cylinders adjustable for interior doors to 5’0” and exterior doors to 4’0”. Non-sized cylinder adjustable for interior doors to 4’6” and exterior doors to 3’6”. Closer mounts parallel arm, specify right or left swinging door. 4111 cylinder meets ADA requirements. The cush hold open arm allows for a stop and hold open positions up to 110 degrees. "T" handle on arm will release door for closing, locking pin can be retracted for normal door closing operation.

We ship the 4111 HCUSH

Dor-o-Matic 1690/1990 bottom rod. Connects panic bar to the bottom latch

Doromatic Part # 4270101825 PB25 and GPB25

Dor-o-Matic 990/1990 Repair Parts Breakdown
Dor-o-Matic 1690 Repair Parts Breakdown

Von Duprin NL Drive Screw 090074

The 090074 NL Drive Screw is used on the Von Duprin 22, 98 and 99 Exit Devices to control the rotation of the key cylinder cam. This small set screw, screws into the back of the chassis assembly next to the receptor for the Rim Key Cylinder. The set screw measures 5/16" long by 3/16" diameter. Note: When the NL drive screw is left in back of device, the outside cylinder will function only as a Night Latch. The Night Latch function means the door can only be opened, but not dogged open with the key cylinder.

Von Duprin Part # 090074
Old Von Duprin Part # 970441

Sanymetal Toilet Partition Keeper Bumper For Concealed Latches 1-1/4" Round Edge Post

Polished chrome plate Zamac die casting construction. Strike and Keeper measures 1-1/4" high by 2-3/8" wide by 1-3/4" deep. Stop is 1/2" thick and projects out 1-1/8". The latching slot is 7/16" deep x 3/4" high. This Bathroom Toilet Door Keeper is designed for use on 1-1/4" thick round edge posts or pilasters. Also known as a Bathroom Stall Strike and Keeper for Inswing/Outswing 1-1/4". Manufacture part # 5510.

Shipped with mounting screws.

Von Duprin 22 Control Link Pin

The control link pin is the connector pin, that connects the latch head assembly to the push bar assembly. When the push bar is pushed in it retracts the latch bolt and the pin connects the two pieces. This Control Link Pin is used on the Von Duprin 22, 33A, 98 and 99 Panic Devices.

VON DUPRIN PART # 050529
Old Von Duprin Part # 969520

International Door Closer 851 Series

FEATURES

Two Adjustment Valves: Closing and Latching speeds controlled by separate regulating Valves,

Universal application Non-handed for standard top jamb or parallel arm installation. Ships with regular and parallel arm bracket

3/4" x 6-3/8" mounting holes

International Door Closer 852 Series
FEATURES

Two Adjustment Valves: Closing and Latching
speeds controlled by separate regulating Valves,

Universal application Non-handed for standard top jamb or parallel arm installation. Shipped with regular and parallel arm bracket.

3/4" x 7-3/8" mounting holes

Von Duprin 8827 Top Rod Connector

Inserts into rod so the latch can connect to the rod. The top vertical rod does not ship with the top rod connector!

Von Duprin Part # 050279
Old Part # 960577

The KB300 series surface mounted horizontal baby changing station is constructed of polypropylene and features a unibody steel chassis for superior strength. Available in three stunning colors with each providing a modern visual aesthetic. Thoughtful patron amenities enhance the end-user experience, and include Microban product protection, a redesigned liner dispenser and the Koala brand mark that communicates comfort to families and the promise of a thoughtful accommodation.

The dual liner cavity has an internal spring tab that pushes liners forward while only allowing single liner dispensing. Each cavity holds 25 liners and locking mechanism minimizes operator refills and discourages potential vandalism. The product includes child protection straps. Bed surface exclusively contains Microban® antimicrobial product protection that reduces odor-causing bacteria and keeps the bed surface cleaner between cleanings. Concealed pneumatic cylinder provides controlled, slow opening and closing of the changing station bed.

Von Duprin Strike 1409

This Von Duprin Strike is used for the bottom latch of the 22, 33, 33A, 55, 88 and 99 Rim Devices.  Also known as a Blade Stop.

Bobrick SCRC solid phenolic alcove partitions 1080/1090 series with overhead braced floor mounted stalls. Alcove stall includes 36" door, 2 pilasters and panel divider to make up the balance. Doors can be either in or out swing you choose. Standard stainless steel hardware included. 3-4  week delivery from the factory.

Bobrick Phenolic Color Chart

Bobrick 1080 Instructions

Bobrick 1090 Instructions

International Door Closer 855 Series-Discontinued.   If you order this door closer the 885 will be sent, it is the same door closer but also features back check.

FEATURES
Two Adjustment Valves: Closing and Latching speeds controlled by separate regulating Valves, Universal application Non-handed for standard top jamb or parallel arm installation.

Ships with regular arm and parallel arm bracket.

3/4" x 9-1/16" mounting holes

Lyon Locker Nano Roller Lock bar Catch, Used September 2004 - Current. Used in the Lock bars, This is the part that latches to the frame of the locker. Also known as 6799. Includes the clips and spring,

The 1085/1285/2086 is mounted on the frame at the top of the door and in the floor at the bottom.   The Package includes the Strike, Plate, Latch Adjusting Wrench and the Mounting Screws.   Jackson Part Number 30-0846.

• Designed for use on all Type 161 Cylindrical Locks (ANSI 156.2 Series 2000)
  Monolock and Unilock.
• No exposed fasteners on face of unit.
• Unique design provides maximum security, virtually eliminating the
  opening between door and frame at latch point.
• Available in 13 Gauge Stainless Steel or 12 Gauge Steel.

1-1/2" Wide x 7" High
Stud center to center: 4-1/2"
