Product Description & Features
• Total Projection: 3-5/8" (92mm)
• Mounting Requirements:
2" x 4" x 1-3/4" (51 x 102 x 45mm)
outlet box
• Wall must be properly reinforced and
outlet box adequately fastened
• UL listed door holder

LCN 8310-3822TW Actuator Package

This package is recommended for interior use only!   Actuator package, 1-1/2" x 4-3/4", includes:
2 8310-818T Wireless Jamb Mount Actuator
2 8310-819S Surface Mount Boxes
2 8310-844J Jamb Mount Transmitter
1 8310-865 Receiver

LCN Part # 8310-3822TW

Adams Rite 91-0993-IP 8700/8800 Strike is used on the rim devices that have the Star Wheel Latching System.  The strike measures 2-3/4" long by 1-3/4" wide and projects out approximately 1/2".   Kit comes with mounting screws and two shims.

The Anodized Aluminum Neoprene Door Shoe is an aluminum U channel to mount on the bottom of doors.  The channel is 1 inch deep with a 1/2 inch neoprene seal on the bottom.  Fits over the bottom of 1-3/4 inch thick doors.  Ships in 36 or 48 inch lengths and comes with #6 x 3/4 inch stainless steel screws.

Brackets designed to mount plexiglass/acrylic sheets to desk surface edge when creating separation/barrier. Brackets are adjustable for thickness from 1/8" to 3/8". It is recommended for use of 1/4" Thick material. Sold as a Pair. Made of Aluminum Alloy. Screws and inserts included. Uses a 5mm/3/16" Allen Key(Not Included) to install screws These are available in either Silver or Black Finish. Silver Finish are readily available while Black Finish may have an extended leadtime depending on quantities being ordered.

Measurements

Height: 2-1/2"

Width: 1-3/4"

Depth: 5/8"

Weight:About 1.3lb

Top to Bottom: 3-5/8"

Plate Width: 1-3/4"

Plate Length: 5-3/4"

Plate Height: 3/16"

Gap/Spacing: 1"

Chrome Plated Partition Keeper Bumper Flat Stop Outswing Door

Chrome plated Zamac die casting. The strike and keeper is 1-1/4" high by 1-3/4" deep by 1/8" thick. The stop is 1/2" deep by 1-1/4 wide with a rubber insert. Also known as a Bathroom Stall Strike and Keeper Outswing Flat. Manufacture part # 5640.

Shipped with mounting screws.

Roto Casement Sash Lock

Housing measures x 4-3/4" tall by x 3/4" wide. The hole spacing is 3-15/16" center to center. The lifting finger projects out 1-1/8"" with the cut out measuring 11-16" deep by 5/16".

Threaded spring clip for round legs. 1/4-20 thread for use with our LA10625 and SLA12525. 1" outside and 7/8" inside diameter. This spring clip has a 1/4-20 thread.

Stainless Steel global slide latch with indicator and emergency access. Overall dimension 2-3/4" x 1-1/2" with 2-1/4" hole spacing. Used with new style doors 10/1/21 to current. Used with a 1 inch door. Security screws included. Manufactures part number 40-8263010.

Global Partitions Top Hinge For 1-1/4" Round Edge Post

Chrome plated Zamac die cast construction. Pivot hinge is 2-3/16" tall by 1-1/4" wide. The slot that wraps around the post is 1-1/4" wide and 11-16" deep. The hole spacing is 1-1/2" on center. The lug projects out 1-1/2" and is 1/2" thick. The bushing on the lug is 3/8" diameter. Also known as a Bathroom Stall Pivot Hinge Top 1-1/4". Manufacture part # 3510.

Shipped with mounting screws.

A=1-7/6"

Global Partitions Bottom Hinge For 1-1/4" Round Edge Post

Chrome plated Zamac die cast construction. Pivot hinge is 2-3/16" tall by 1-1/4" wide. The slot that wraps around the post is 1-1/4" wide and 11-16" deep. The hole spacing is 1-1/2" on center. The lug projects out 1-1/2" and is 1/2" thick. The bushing on the lug is 5/16" diameter. Also known as a Bathroom Stall Pivot Hinge Bottom 1-1/4". Manufacture part # 3010.

Shipped with mounting screws.

A=1-7/6"

American Sanitary Partitions Keeper Bumper For 1-1/4" Outswing Square Edge Pilaster Or Post

Zamac die casting that is polished chrome plated. The strike and keeper is 2-1/2" tall by 1-7/8" wide. The stop sticks out 3/4" and has a rubber bumper on it. The two mounting screws are 1-1/2" on center. This keeper bumper is designed for use on a 1-1/4" Post or Pilaster for outswinging doors. Also known as a Bathroom Stall Strike and Keeper-Outswing 1-1/4". Manufacture part # 5210

Shipped with mounting screws.

4" long

Lyon Metal Locker Handle Assembly for right handed lockers, facing the locker if the hinges are on the right side then they are a right handed locker. Assembly includes case, lift and 4 screws. November 1965- September 1981. Also known as 6741 and 6742, 75030, ly2230, ll1746. Hole spacing for the lift is 1-3/4". Hole spacing for the case that mounts to the locker is 3-1/4".

Lyon Metal Locker Handle Assembly for left handed lockers, facing the locker if the hinges are on the left side then they are a left handed locker. Assembly includes case, lift and 4 screws. November 1965- September 1981. Also known as 6741, 6756, 75031, ly2231, ll1748.Hole spacing for the lift is 1-3/4". Hole spacing for the case that mounts to the locker is 3-1/4".

Durabilt Locker Handle. 3-3/4" centers. Also known as 90101, 72001, db7755.

Casement Window Operator 9" Arm

Replacement Casement Window Operator is made of a die cast housing and steel arm. The window operator housing has 4 mounting holes, 4-3/4" are the outside dimensions of the outside screws and 3-7/8" on the inside screws.

Right Hand Operator Shown in picture

General Toilet Partition Keeper Bumper For Square Edge 1-1/4" Thick Posts

Zamac die cast construction and polished chrome plated. The keeper and strike is 2-1/2" tall by 1-7/8" wide. The stop is 17/32" thick and projects out 3/4". The mounting holes are 1-1/2" on center. The locking slot is 7/16" deep. Generally used with concealed latches. Also known as a Bathroom Stall Strike and Keeper - Inswing/Outswing 1-1/4". Manufacture part # 5230.

Shipped with mounting screws.

Concealed Partition Latch Keeper Bumper Inswing Cast Stainless Steel

Stainless steel casting. The strike and keeper is 1-1/4" high by 2-1/2" deep by 1/8" thick. The stop is 1/2" deep by 1-1/4 wide with a rubber insert. The slots are 1/4" deep. Also known as a Bathroom Stall Strike and Keeper Inswing Flat. Manufacture part # 5653.

Shipped with mounting screws.

Roto Pro Drive Folding Handle

The Roto Pro Drive Folding Handle features die cast construction, and powder coated finish.   The hex is 5/16", and the handle has a overall length of 4-1/4".

Wall Mounted Door Stop WS443

Features:

• Constructed in brass.
• Ideal for interior or exterior use.
• Non-marring rubber tip.
• Packed with expansion shield and lead shield.

Diameter 2-1/4"
Projection 3-11/16"

• Not load-bearing
• Available 3/4"(19mm) offset only
• Non-ferrous base material
• Used with 117, 117-1/4, 195, UNI closers,
127 closer
• Maintains door alignment
• Furnished with wood and machine screws

Handing diagram

Cone Style Table Stool Tops-Universal Fit. Made of heavy duty HDPE Plastic. The Stool Tops are shipped with Stool Top, Cone, Fasteners, and Cone Sleeve. The removeable Cone Sleeve allows use with 1" and 1-1/4" diameter mounting tubes. The Stool measures 12-1/2" diameter and is 15/16" thick. The Cone measures 4-1/2" high. This Stool Top will work with 99% of the tables out there. Available in Black, Burgundy, Charcoal, Dark Blue, Royal Blue, and Red.

Curtain Hook For 1"- 2-3/4" High

The baby changing tables are a horizontal station, has a door facing and collar made from 18 gauge 304 stainless steel. Fabricated of FDA approved fungus and bacteria-resistant plastic. Unit complies with 2010 ADA Accessibility Standards and supports a static load of 300 lbs. This unit is used for recess mounting , also know as part number 9018 with American Specialties.

Partitions Toilet Top or Bottom Hinge for plastic laminate doors used for top or bottom for 1 1/4" square edge post. The hinge mounts to the post to support the door. Chrome plated Zamac die cast construction. The hinge measures 2-1/4" high by 1-1/4" deep with a slot depth of 1-5/16" and 1-1/2" between screws on center. Hinge lug projects out 1-11/16" and is 1/2" thick with a 5/8" diameter hole. Also known as a Bathroom Stall Pivot Hinge Top/Bottom 1-1/4". Manufacture part # 3540. Same as 9G631A on our website.

Available in Recessed, Semi Recessed and Surface mount. Fabricated of 22 gauge stainless steel with satin finish. Wall Opening: 15 3/4” x 26” x 10” Power Source can be hard wired is (AC) or Battery Operated (A) Battery not supplied, 4-D Batteries. Automatic Mechanism. Unit automatically dispense one predetermined length at a time when hands are placed in the sensor zone. The owner can determine the length of sheets.

replacement valve Valve threads are 3/4" o.d. 28 treads per inch

One inch diameter solid push bar, 2-1/4 inch projection with 1-1/4 inch clearance and 33-1/16 inch centers.  One side is thru bolted the other is mounted on a surface mounted stud.

Metpar Toilet Partitions Keeper Bumper For 1-1/4" Inswing Square Edge Pilaster Or Post

Zamac die casting that is polished chrome plated. The strike and keeper is 2-1/2" tall by 1-7/8" wide. The stop sticks out 3/4" and has a rubber bumper on it. The two mounting screws are 1-1/2" on center. The latch bolt slot is 1-9/16" high by 5/16" deep. This keeper bumper is designed for use on a 1-1/4" Post or Pilaster for inswinging doors. Also known as a Bathroom Stall Strike and Keeper-Inswing 1-1/4". Manufacture part # 5110

Shipped with mounting screws.

Metpar Partitions Slide Bolt Latch with indicator Chrome plated Zamac die cast construction. The latch housing face plates measure 1-3/4" wide by 1-1/4" high. The latch thickness is 1-1/16". The latch bolt measures 3/4" by 3/16" with a 15/32" throw. Also known as a Metpar Bathroom Stall Concealed Latch. Manufacturer part # 4240, 13882. Metpar Toilet Partitions is the only manufacture that we know of that uses this latch.

Occupancy Indicator Latch Handle is constructed of cast stainless steel with a satin finish. Latch handle is designed for 3/4" Doors and is through mounted to the occupancy indicator. Features a 4-1/2" length handle that is tapered at one end to engage with keeper for locking. Features emergency unlatching access on front of indicator. Shipped with fasteners for mounting occupancy indicator to door and pilaster. Known as manufacturer part number 4993.

projects 2", ht 1-3/4"

Trim Protector Bar

A great product for applications were your door knobs and levers are getting damaged due to hand carts and other items hitting door trim. Mount this product above or below existing items on walls and doors to protect and sheild them from damage.

Material: Brass, Bronze, Stainless Steel
Material Size: 3/8" x 1-1/2"
Base: 1-3/4" x 3-1/2"
Projection: 3-1/4"

Hamilton Stool Tops. The Hamilton Stool Top measures 12-3/4" diameter x 7" diagonally between screws. This School Cafeteria table seats are available in Black, Burgundy, Marine Blue, Red and Royal Blue.

KTHAMBU-Burgundy
KTHAMA-Black
KTHAMU-Royal Blue
KTHAMR-Red
KTHAMMB-Marine Blue

Product Description & Features
• Total Projection: 4-1/8" (105mm)
• Mounting Requirements:
1-1/2" (38mm) deep adapter housing
• UL listed door holder
