Inswing Partition Keeper Bumper For Throw Latch For 1-1/4" Sq Post

Zamac die cast and polished chrome plate construction. The strike and keeper measure 2-1/2" high by 1-7/8" wide with a hole spacing of 1-1/2" on center. The stop is 2-1/2" tall by 3/4" wide with a rubber insert. The slot measures 13/16" high by 1/4" deep. Commonly known as a Bathrrom Stall Strike and Keeper Inswing 1-1/4". Manufacture part # 5340

Shipped with mounting screws.

Chrome Plated Toilet Partition Keeper Bumper Flat Stop 1-1/2" Between Screws

Polished chrome plated Zamac construction. The strike and keeper measure 2-1/2" high by 1-13/16" deep by 1/8" thick. The stop has a 3/4" projection and is 9/16' deep with a rubber insert. The mounting holes are 1-1/2" on center. The slot is for the concealed latch is 7/8" high by 7/16" deep. Also known as a Bathroom Stall Strike and Keeper Inswing/Outswing Flat. Manufacture part # 5240

Shipped with mounting screws.

• For automatic closing of doors
• Packed with wood and metal screws

This hinge is not recommended for doors that have a sweep larger than 110 degrees.

Sold in Boxes of 3 Hinges
Shown in brushed brass

Application
includes 180 top pivot
Interior Doors
Weight to 300 lbs.*
Door Width up to 3'6"(1067mm)
Handed

Handing diagram

The Partition Privacy Covers, Great for Restroom Partition Door Gaps. Block's gaps between door and pilaster for both sides. Includes 2 per package, one for each side of door, 58" Tall.  The Cover is just under 2" wide with the clear rigid vinyl mounting strip being 7/8" wide, and the cover being 1-1/8" wide. This product ships in an oversize box ground. This product is not recommended for solid plastic partitions, HDPE or solid polymer material. This is great for powder coated steel, plastic laminate, stainless steel and solid phenolic materials only.

The informational and installation video are shown in the Description Tab below. In Stock for quick deliveries.

General Toilet Partition Keeper Bumper For Square Edge 1-1/4" Thick Posts

Zamac die cast construction and polished chrome plated. The keeper and strike is 2-1/2" tall by 1-7/8" wide. The stop is 17/32" thick and projects out 3/4". The mounting holes are 1-1/2" on center. The locking slot is 7/16" deep. Generally used with concealed latches. Also known as a Bathroom Stall Strike and Keeper - Inswing/Outswing 1-1/4". Manufacture part # 5230.

Shipped with mounting screws.

C-Fold, Multi Fold Towel Dispenser and Waste Receptacle
22 gauge Type 304 Stainless Steel
Heavy duty door and piano hinge
Tumble lock on doors and waste receptacle
600 C-fold or 800 Multi-fold towel capacity
12 gallon waste receptacle
h15"w x 54" x 4"d hole opening
17-1/4"x56"ht x 4" overall dimension.

Hold Open Cushion Arm for the CRL PR90, Cal-Royal CR441 and International 44CI door closers.  For use in parallel arm applications only, T Handle locks the door in the open position.

The Dor-o-Matic Falcon 4758959 Soleniod is used on the EL1690, EL1790, and EL2390 Electric Latch Retraction exit devices.  The Solenoid measures 4-1/8 inches long including mouting flange, and has an 1-3/4 inch diameter.  The mounting screw spacing is 1 inch on centers. The Plunger is included and has a 7/8 inch diameter and is 2-15/16 inches long.  We find the number 971687 on the solenoid.

7-1-2025 No longer available.  If you have the 1690 or 1790 you can update your exit to the new mortor 47867200

• For standard weight doors
• Low frequency usage
• Packed with wood and metal screws
Not for use with a door closer.

Sold in boxes of 3
Shown in brushed brass

Cal Royal 2000 Series Exit Device Lever Trim

Non-handed Grade 1 (Clutch Style)
Cylindrical body hardened steel heavy duty tailpiece. For
1¾” and 2 ¼” doors. Prefix THI before part # for 2 ¼” door
thickness. Available for fire and non fire rated rim and
vertical rod exit devices.
Rose diameter 3 ½”, lever length 4 ¾”.

Penco Locker Bottom Cam Assembly for double door lockers.

Step N Pull®

Stop the spread of germs with this ingenious product. Simple step on the plate and pull the door without grabbing the door pull.

Includes:

1. One StepNpull®
2. Required mounting screws
3. Two stickers, one for the door and the other for the mirror, paper towel dispenser or hand dryer. Actual dimensions are 5"x4"

Currently we only have Aluminum in stock.
Available in Aluminum, Gold or Copper Finish-See Color under "More Views"

Von Duprin Electric Strike 6114 24VDC

Von Duprin 6100 Series electric strikes are designed for use with Rim devices.  The 6114 has a 3/4” latch bolt throw, 7” face plate length, 1-7/8” width, and projects1-9/16”.  The lock retrofits the Folger Adams FD 310-5.  Other voltages and replacement parts are available.

FSE - Fail-secure.  Requires power to be applied to unlock the strike lip.  On loss of power, the strike lip is locked-Fire Rated

FS - Fail-safe.  Requires power to be applied to lock the strike lip.  On loss of power, the strike lip is unlocked.  Non Fire-Rated.

C-Fold, Multi-Fold Paper Towel Dispenser
22 gauge Type 304 Stainless Steel
Heavy duty door and piano hinge
Tumble lock on doors and waste receptacle
600 C-fold or 800 Multi-fold towel capacity
13"w x 26"h x 4"d

C-Fold, Multi-Fold Paper Towel Dispenser
22 gauge Type 304 Stainless Steel
Heavy duty door and piano hinge
Tumble lock on doors and waste receptacle
600 C-fold or 800 Multi-fold towel capacity
13"w x 26"h x 4"d

The Dorma RTS88 Top Arm 8831is for use on Single and Double Acting doors.  This is the standard arm in the RST01 and RST02 Packages.

Dorma Part # 8831

Toilet Partition Heavy Duty Vault Hinge Set Stainless Steel For 3/4" Or 1" Thick Doors

Stainless steel construction. For 3/4" to 1" thick doors and 3/4" to 1" posts and pilasters. Also known as a Bathroom Stall Roller Bearing Hinge Set. Used by all of the Toilet Partition manufactures on there Solid Plastic (HDPE) Restroom dividers. Manufacture part # 7813.

Shipped with screws.

Roval Dual Sanitary Napkin & Tampon Dispenser Dispenses 31 napkins and 22 tampons. Door made of 18 gauge type 304 satin finish stainless steel, with two flush tumbler locks. Universal coin mechanism is convertible for 25 cents, 50 cents or FREE (no coin) operation. Coin boxes have different lock and key than doors. Wall Opening: 15 5/8" W x 25 7/8" H x 4" D

Von Duprin 050535 El Solenoid Assy

Discontinued, we do not have any stock remaining.  You would have to order the QEL or QEL-HD Conversion Kit to update your exit to the new Mechanical Electric Latch Retraction:  https://www.robertbrooke.com/von-duprin-qel-baseplate-conversion-kit.html

Screws are 1" on center, the cylinder measures 3" long by 1-3/4" diameter. Used on the 33A, 35A, 98 and 99 exit and panic devices. This Solenoid Assembly is also used on the Doromatic/Falcon EL1690, EL1790 and EL2390

We sometimes find the number 971687, along with 4011 VDC 24

Von Duprin Part Number 050535
Doromatic/Falcon Part # 971687-00

2600 Series Electronic RFID Locks are some of our most secure and versatile electronic locks. They work on all standard single point lockers, box locker, gravity latch/multipoint, wood, phenolic, plastic and laminate lockers. They are designed to meet the same security levels used in Smart cards. Complying with all ADA guidelines for accessibility.

• Unique card key with same security level as used in banking Smart Cards
• Complies with all ADA guidelines for ADA accessibility
• Engineered to work on all standard metal single point, box locker, gravity latch/multipoint lockers
• Wood, laminate, phenolic lockers and casework will require extension kits of 1/2″ or 3/4″ for thicker material
• Supervisory override card and program card capability
• Programmable for both day use and permanent use
• High impact polycarbonate housing
• Ability to track user history
• New user cards available in the event card is lost
• Battery Powered; Requires (4) AA batteries offering life cycle of 10,000 – 20,000 uses depending on model
• Low battery audible warning signal
• External battery powered emergency device offered to allow access to lock if low battery signal is missed and battery life ends
• Permanent use will lock automatically
• Shared use will not lock automatically
• Management codes are 6 digits with default or choice for factory to preset.

OPTIONS:

• Available 1 year warranty from the time of shipment

APPLICATIONS:

• Athletic, student & swimming facility lockers
• Health, fitness, golf & country clubs, day spas, wellness centers; hotel & resort lockers
• Employee lockers

Von Duprin Electric Strike 6112 24VDC

Von Duprin 6100 Series electric strikes are designed for use with Rim devices.  The 6112 has a 3/4” latch bolt throw, 9” face plate length, 1-5/8” width, and an 1-3/4” backbone depth.  The lock retrofits the Folger Adams FA 310-4.  Other voltages and replacement parts are available.

FSE - Fail-secure.  Requires power to be applied to unlock the strike lip.  On loss of power, the strike lip is locked-Fire Rated

FS - Fail-safe.  Requires power to be applied to lock the strike lip.  On loss of power, the strike lip is unlocked.  Non Fire-Rated.

• Through-bolted: 1-3/4" (44mm) door standard. For doors through 2-1/4" (54mm)
• Plate Dimensions: 3-1/2" x 3-3/4" x 3/32" (89mm x 95mm x 3mm)
• Finger Pull Dimensions: 3-1/2" x 6-3/4" x 1/8" (89mm x 171mm x 3mm)

The Lock Guard with Security Pin is ideal to cover the latchbolt area of the door, lock and frame, with the added protection of a security pin to prevent separation of the door and door frame.  The plate is through bolted with carriage bolts and nuts, which are included with the guard.  The plate is constructed of 13 gauge stainless steel.  The plate measures 3" wide and 11-1/2" high, with a center to center on the mounting bolts of 10-1/2".

Comtec Toilet Partitions 8" Ada Hinge Set, 3 Hinges Total. Clear anodized aluminum for 1" panel and 1" door. Used by every Bathroom Toilet Stall manufacture on Solid Plastic Toilet Partitions Doors. Manufacturer part #'s 7978, 7988, 8974, 8984. These hinges are reversible by taking the 3 pieces apart and reconfiguring the opposite swing.

C-Fold, Multi Fold Towel Dispenser and Waste Receptacle
22 gauge Type 304 Stainless Steel
Heavy duty door and piano hinge
Tumble lock on doors and waste receptacle
600 C-fold or 800 Multi-fold towel capacity
12 gallon waste receptacle
15"w x 54"h x 4"d

The Von Duprin Mullion Stabilizer Package are used with Von Duprin Mullions to stop any deflection on the mullion, which may cause the exit devices to release.  We run into issues where people are able to shake the door, and the door opens.   The package includes two sets of stabilizers and all the mounting screws.

Lyon Locker Catch Clip replaces the Nano Roller type. Also known as 6808. Used January 2013 to current. Replacement part that is used on the lock bar that catches the door frame to lock the door. 1/4" x 1/2" x 2-1/2" in length with spring included.

• For heavy weight doors
• High frequency usage
• 4 ball bearing
• Packed with wood and metal screws

Sold in boxes of 3 Hinges
Shown in brushed chrome

The Cal-Royal CRCODE204 is for use with the 2200, 7700 and 9800 Rim and Surface Vertical Rod Devices. The Lever Mechanism features a Break Away Lever, for use with 1-3/4 inch to 2 inch thick doors, non-handed, Single Code User, Key Override, easy on the door code change, weather resistant, and more than 8000 non-sequential possible code combinations.

Installation and Programming Instructions

Extension Kit No.1901 for mounting of Built-in Combination Locks on 11/16" to 3/4" thick wood or laminate locker doors.

Global Partitions Top Hinge Pin

Zinc plated steel construction. The hinge pin is 3/8" diameter by 3-3/4" long. Also known as a Bathroom Stall Door Hinge Pin. Manufacture part # 98544.

• Not load-bearing
• Maintains door alignment
• Non-ferrous base metal
• 3/4"(19mm) offset
• Furnished with wood and machine screws

Handing diagram

The Von Duprin 970323 299 Strike Adjustor is the piece that secures the placement of the Strike to the door frame or mullion.

1" diameter material
Establish the center to center dimension by subtracting the width of one stile from the width of the door. On solid doors, subtract 5" from the width of the door.

Please specify either wood or metal door, and its thickness; we'll supply
appropriate fasteners.

Please allow 3-4 weeks on Aluminum and Dark Bronze, and 2 weeks on the other finishes

Finishes

Monarch Falcon 25-V Vertical Rod Exit Device

The Monarch Falcon 25-V is designed for high-traffic applications were added strength and durability are required.  The device includes all strikes and mounting screws required for installation.  Available in 3' and 4' devices, the 3' device is for doors 30" to 36", the 4' device is for doors that are 37" up to 48" wide.  The vertical rods furnished with this device are for doors up to 7' tall, if your doors are taller, please contact us.
