ASI locker recess lifter handle in black color. The lifter attaches to the lock bar which releases the door from the frame and unlocks the door. This is an Ada locker handled and is now a standard in the locker industry. The trigger is now sold separately if this is all you need.

Door Pull 11

This door pull has 8" center to center screw spacing. The base is 3/4" diameter, the overall lenght is 9-1/4". The projection is 2-1/8" and the clearance is 1-1/2". Also known as a 8" Center Door Grip or Door Handle. This handle is shipped with thru bolts and finish washers.

Aluminum and Stainless Steel ship in 1 week, all other finishes ship in 2 weeks. Made in the USA.

Finishes

Project In Handle With Ring Pull 1-1/2"

This window handle has a 1-1/2" hole spacing with a C Dim 7/16" lock dimension. The handle is constructed of a white bronze casting that is then brushed nickel plated.

Single Hole Cam Handle

This handle is only available in the brushed bronze finish, the window handle is constructed of cast red bronze. We find this handle used with Fenestra Windows.

Right Hand S228RH
Left Hand S228LH

Handicap Door Pull 18

With this handle you are able to get a closed fist behind the pull, which makes it a great ADA Door Pull. Shipped with screws. Also known as a Handicap Grip, ADA Door Pull or Handle.

Finishes

Two Hole 1-1/4" Window Handle 5/16" Lockup With Ring Pull

This window handle features a 1-1/4" hole spacing, a 5/16" lock up dimension and a ring pull for elevated windows. This handle is cast white bronze construction with a brushed nickel finish

Norton Door Closer Rod and Shoe

The Norton Rod and Shoe 7701-11 and 7701-11A come in two different lengths, 8-7/8" anc 12-1/2".  The length is measured from the end of the bar to the center of the eyelet.

Norton Part #'s:
8-7/8" Long  7701-11
12-1/2" Long 7701-11A

Door Pull 4" Centers Chrome Plated. Chrome Plated die cast handle. 4-3/8" wide x 7/8" projection, also known as 9a0171.

LCN Door Closer Rod And Shoe

This piece fits into the female part of all LCN Regular Arms. The old style had two concave set screws and a ball pressed into the rod. If the door over rotated the ball would pull out of the concave set screws. The new version has a pin holding the rod to the shoe which is designed to fail if the door is over rotated. This piece will work on the LCN 1260, 1460, 4010, 4020, 4030 and 4040 door closers with regular arms. Some of the really old models have multiple threaded holes, so you might have to drill a hole in the female tube. Part #'s 4040-79, 4040-79LR and 4040-79ELR. The 1260, 1460, 4010, or 4020 could replace the 4040 in those part numbers, they are the same.

LCN Door Closer Head and Tube

The LCN Door Closer Head and Tube comes in two versions.  One is 5-3/4" long and the other is 8-5/8".  The square hole is 5/8",   This part usually goes by the part number 4040-78H, 4040-78HL, 1260-78H, 1260-78HL, ect.,.

Door Pull 17

This door handle has an overall length of 10". The base diameters are 2" with three holes each. The handle projects out 2-1/4" and has a clearance of 1-1/2". Also known as a Door Grip or Door Handle. This handle ships with 6 wood/sheet metal screws.

Finishes

The Partition Double Door Pull 5-1/2" stainless steel come as two handles for mounting back to back handles on an one inch thick door.  The handles have 5-7/8" center to center hole spacing, and the screws included are for a 1" thick door. This is constructed of cast brushed stainless steel. The manufacturer part number on this part is 900112. Overall width is 6-3/4"

Handicap Door Pull 119

With this handle you are able to get a closed fist behind the pull, which makes it a great ADA Door Pull. Shipped with screws and finish washers. Also known as a Handicap Grip, ADA Door Pull or Handle.

Finishes

Black Occupancy Indicator Latch Handle is constructed of cast stainless steel with black finish. Latch handle is designed for 3/4" Doors and is through mounted to the occupancy indicator. Features a 4-1/2" length handle that is tapered at one end to engage with keeper for locking. Features emergency unlatching access on front of indicator. Shipped with fasteners for mounting occupancy indicator to door and pilaster. Known as manufacturer part number 4995.

The Swivel Glide 5/8" O.D. with Ferrule Outside Holding Clip Nylon Base is used on American Desk, Artco Bell, Carter Craft, Krueger, Peabody and Virco Chairs. Nylon or Plastic Base Glides slide easily across floors as long as the floor is free of grit and grime.  When you do have grit or grime on the floor, it gets impregnated in the nylon and will scratch the floor.  The top freely swivels beyond 30 degree angle. Glide grips leg with outside holding clip, meaning it grabs and holds on to the outside of the leg, see more views for picture of outside holding clip.  This glide is designed for 5/8" outside diameter legs, and the base is 1-1/4" in diameter.

Truth Two Hole 1-1/2" Window Handle

Truth 25.31 Two Hole Cam Handle die cast construction with a powder coated painted finish. We find the numbers 45086 on the right hand handles, and 45085 on the left hand handles.

Right Hand shown in picture.

Fenestra Windows Casement Handle

Stamped steel construction, 2-5/8" center to center mounting holes

Used on steel framed Fenestra Windows

Right Hand Shown in Picture

Door Pull Offset 1" Diameter PH-4000

1" Diameter Solid Aluminum Round 3-1/4" Offset Door Pull, usually used on aluminum frame glass doors. This handle offers three different mounting options, one is surface mounted, where the handle is mounted over a mounting stud and then you tighten the set screw to hold the handle in place. The second method is thru bolted, the bolt goes all the way thru the door. And the third is back to were you have two handles mounted back to back.

Projection 3 -1/4"
Door Clearance 2 -1/4"
Center To Center 9". 10' and 12"
Anodized Finishes Aluminum or Dark Brown
Mounting Hardware Included

The GS620D Rubber Stair Tread with Grit Stripping. The GS620D is only available in the square nose.   This tread offers an 1/8" nose thickness, has an adjustable and tapered nose. You have two choices on the Grit Stripping, the Visual Impaired 1-2" wide or 2-3/4" wide grit tape strips. They are designed for interior use.

Ives Dome Door Stop 1-3/8" FS438

Features:

• For doors with threshold or undercut doors.
• Heavy-Duty Cast Dome Stops constructed of brass, bronze or aluminum.
• Gray, non-marring rubber bumper.

Overall hgt 1-3/8"
Base Hgt 9/16"
Base Diameter 1-3/4" x 2" Oval

Handicap Door Pull 19

With this handle you are able to get a closed fist behind the pull, which makes it a great ADA Door Pull. Shipped with screws. Also known as a Handicap Grip, ADA Door Pull or Handle.

Finishes

Occupancy Indicator Latch Handle is constructed of cast stainless steel with a satin finish. Latch handle is designed for 3/4" Doors and is through mounted to the occupancy indicator. Features a 4-1/2" length handle that is tapered at one end to engage with keeper for locking. Features emergency unlatching access on front of indicator. Shipped with fasteners for mounting occupancy indicator to door and pilaster. Known as manufacturer part number 4993.

Pella Window Operator Crank Handle. Fits all Pella Operators.

3/8"-11 Spline

Two Hole 1-1/2" Plastic Handle

Constructed of high density plastic with an 1-1/2" hole spacing. The lock up dimension is 3/8". The base measures 2-1/8" x 7/8". The handle measures 3-1/2" long.

The white is instock, the beige has a 1-3 week lead time.

Specify your current closers model number when ordering. Not all
of the LCN closers have the same shape spindle on the door closer
cylinder. Model Available here are the:

1260-3048
1260-3048L
1460-3048
1460-3048L
4010-3048
4010-3048L
4020-3048
4020-3048L
4040-3048
4040-3048L

The size is the tube length.

Metpar Partitions Bottom Door Insert For 7/8" Door

Chrome plated Zamac die cast construction. The door insert measures 2-5/16" wide by 1" wide by 1-3/16" high. The hex shaped hole is 5/8" and the round hole is 7/32" diameter. The material or rim is 5/16" high. Also known as a Bathroom Stall Door Insert Bottom 7/8". Manufacture part # 1530.

The Foot Operated Door Pull is a low cost solution to keep your hands off of high traffic handles. It is constructed of cast aluminum, and measures 4" wide by 1-7/32" high with a 2-3/8" projection. The package includes fasteners, door decal and installation tool.

Nylon based Metal Swivel Glide for a round chair leg with a 1-1/8" O.D. X 1" I.D. This glide does not have a ferrule. This glides base is 1 1/4" in diameter. Metal Furniture Feet for school and institution applications. Nylon base protects your floor as long as the bottom does not have grit and grime on it.

Project-In Kawneer Window Handle

Cast white bronze, with brushed nickel finish.

Used on Kawneer Windows.

We ship the P4907RP as a replacement.

Truth 24.23 Casement Locking Handle

This handle features a 2-3/8" center to center hole spacing with a 1/2" lock up.

Truth Part # 24.23.xx.200 , were the xx is the finish code.
