Project In Truth Window Handle-1-1/2"

This window handle features a 1-1/2" hole spacing on centers with a 7/16" lock up dimension. The window handle is constructed of a die cast material that is then powder coated to the finish of your choice. We stock the Bronze color, but other colors are available, call for more information.

Truth 27.31 project in window handle.

Reinforcing Pivot Hinge - For use with 4-1/2" wide butt hinges

3/4" to center line of 4-1/2" hinge pin.
Pin uses large pin and bushing.
Used to dampen vibration and increase
strength to your full mortise butt hinges.
Constructed of heavy duty cold rolled steel.
Made of Zinc Plated Steel
Supports weights up to 300 lbs

Manufacturer part # B1923
Our part # DR1923 for Right Hand, DL1923 for Left Hand

These hinges are no longer handed, you can select right or left, but the hinges will work both ways.

The Truth Encore Handle and Cover are used on the Encore Operators Wi5110 and Wi5010.  The cover are constructed on Plastic and the Handles are die cast metal.  The ones shown on the website are Right Hand and the color is Bronze.  Once color is selected and hand, the different hands will appear, the color is not correct.

Truth Part Numbers 12614 (Left Hand) and 12616 (Right Hand).

Color Chart

Flat Style Table Stool Tops-Universal Fit. Made of heavy duty HDPE Plastic. The Stool Tops are shipped with Stool Top, and Fasteners. The Stool measures 12-1/2" diameter and is 15/16" thick. The hole spacing is 5" x 5" on center in a square pattern. Flat Style Stool Caps are Available in Black, Burgundy, Charcoal, Dark Blue, Royal Blue, and Red.

Door Pull 24

This door handle features a 6" center to center screw spacing. It ships with thru bolts and finish washers. Also known as a Door Handle or Door Grip.

1" diameter material
6" centers
8" overall
3/4" base diameter
2" projection

Finishes

Ashland Operator Cover measures 4 inches across.  We find the number US Patent Pending P-1080-100 on the Left Hand Covers and P-1080-200 on the Right Hand Covers.

This Ashland Evolutions Cover and Handle measures 5-19/32 inches across.  The Right Hand Cover and Handle work on the Silver Colored Splines, and the Left Hands work on the Gold Colored Splines.

Door Pull 10

This door pull has 5-1/2" center to center screw spacing. The base is 3/4" diameter, the overall lenght is 6-1/4". The projection is 2" and the clearance is 1-1/2". Also known as a Door Handle or Door Grip. This handle ships with thru bolts and finish washers.

Finishes

Truth 15.56 Single Arm Window Operator.

7-1/2" long arm. Ships with matching handle.

Truth Part # 15.56

Bronze only

The Adams Rite 4580 cam is used on the the 4500 and 4900 Dead Latch Paddles.  The 4580-500 is for Left Hand, and the 4580-600 is for Right Hand Doors.

Fenestra Casement Operator

Metal Door Flush Bolt FB458

The Ives FB458 is a UL Listed Flush Bolt for use on Fire Doors. The face plate measures 1" wide by 6-3/4" long with a depth of 1-1/8". Hole spacing is 1/2 inch by 6-1/4 inches on centers. The bolt has a 3/4" throw and is 1/2" diameter. This Flush Bolt is available in Polished Brass, Oil Rubbed Bronze (dark brown) and Brushed Chrome. We try to stock the 12" rods, which are standard, but we can also get 18", 24", 36" and 48"

Ives Part # FB458

Sargent inside/outside spindle

8100 Series rec'g prior to 1/1/1990

includes lever bushings, roll pin and set screws

The Dor-O-Matic 2390 231CA Cylinder Kit converts your 2390 exit only to a Night Latch or Hold Back function key lock.  All the hardware is included in the package to convert your device, except for the Mortise Cylinder.  Housing measures 4-1/2" tall by 1-11/16" wide with a 1-1/8" projection.  We send the 231CA which includes the Schlage B502-191 Cam.   The 239CA is the same kit, but without the Schlage Cam.

Discontinued item, we only have a few left in Dark Bronze.

Top Partition Hinge For 1-1/4" Round Edge Post Or Pilaster

Chrome plated Zamac die cast construction. The outside dimensions of the hinge are 1-1/4" deep by 2-1/2" high by 1-7/16" wide. The U mounting channel is 2-1/8" high by 1-1/4" deep with a slot depth of 11/16". The mounting holes are 1-1/2" apart on center. The lug projects out 1-3/32" by 13/32" thick with a 3/8" diameter bushing. Also know as a Bathroom Stall Pivot Hinge - Top 1-1/4". Manufacture part # 4530. Used on Ampco and Metpar Metal Partitions.

Shipped with mounting screws.

A=1-7/16"

Von Duprin 8827 Bottom Latch

Used on all Von Duprin 8827 non fire rated exits. Included mounting screws.

Von Duprin Part # 050461
Old part # 101751

Truth Entrygard Dual Arm Operator. We would expect you to find 20755 on the bottom of the linkage arm, which measures 3-3/4" overall length. Other common numbers we would expect to find are 31538, 31539, 30841, 30842, 30472, 30470, and 20755.  Call or email for quantity "Discount Codes".

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

3-3/4" link dimension, offset down. For offset up order Wi1516

Order Wi1510 if your link dimension is 4-7/16" stamped 20810.
Order Wi1515 if your link dimension is 2-7/8" stamped 20748.

Left hand shown.

Door Pull 11

This door pull has 8" center to center screw spacing. The base is 3/4" diameter, the overall lenght is 9-1/4". The projection is 2-1/8" and the clearance is 1-1/2". Also known as a 8" Center Door Grip or Door Handle. This handle is shipped with thru bolts and finish washers.

Aluminum and Stainless Steel ship in 1 week, all other finishes ship in 2 weeks. Made in the USA.

Finishes

Replacement spindle for the 8100 and 8200 old style series mortise locks , January 1990 to current.

Includes lever bushings, roll pin and set screws

Door Pull 12

This handle has a 5-1/2" centers hole spacing and is 6" overall. It has 2" projection with 1-3/8" clearance and the base is 5/8" x 1-1/4". Also known as a Door Handle or Door Grip. Shipped with thru bolts and finish washers.

Finishes

Hold Open Cushion Arm for the CRL PR90, Cal-Royal CR441 and International 44CI door closers.  For use in parallel arm applications only, T Handle locks the door in the open position.

Casement Window Operator 9" Arm

Replacement Casement Window Operator is made of a die cast housing and steel arm. The window operator housing has 4 mounting holes, 4-3/4" are the outside dimensions of the outside screws and 3-7/8" on the inside screws.

Right Hand Operator Shown in picture

Door Pull 15

This door handle features 7-1/2" centers on the mounting screws. With 2" diameter bases. The Grip has a 2-1/4" projection with a 1-5/8" clearance. Also known as a Door Handle or Door Grip. This handle ships with thru bolts and finish washers.

Finishes

International 521 Forearm

Arm measures 9-1/2" loop to loop in the shortest position, and 14" when it is the fully extended . The loop on the left side is 3/8" diameter. The hole spacing on the right hand side of the picture shoe is 1-3/4".

International part # 521

Norton / Yale Door Closer Arm Shoe Assembly

Replacement Shoe Assembly for Norton 1600, 9300, 7500 and 8000 series door closers. And Yale 50, 2300, 8000 and 4400 series.
Base measures 11/16" x 2-1/4" with 1-3/4" center to center screw hole mounting. Bracket projects out 15/16". The pin is 3/8" diameter.

Norton part # 7701AS or a Yale # 400-AS

Old Norton Part # 1620AS

Standard new 4030 series closer is shipped with forged regular arm, metal cover and wood/self-tapping machine screw pack. Non-sized (1-4) 4031 cylinder for exterior doors to 36” (914 mm) and interior doors to 48” (1219 mm). Closer mounts hinge side, top jamb, and parallel arm, on either right or left
swinging doors. Closer meets ADA requirements.

ADA Sliding and Barn Door Push/Pull Set. Pull handle is 3/4" round stock with 6" center to centers and 2-1/2 inch clearance.  The flush pull is 4" x 7" x 1-1/8 inch ADA.

The Truth-Wright Split Arm Operator is a replacement for the older Wright Operators.  Linkage arm has an overall length of 3-5/8".

Left Hand Shown in Picture, we can only get these in white.

Project In Truth-1-1/2"- 1/2" Lock Up

This window handle features a 1-1/2" hole spacing on centers with a 1/2" lock up dimension. The window handle is constructed of a die cast material that is then powder coated to the finish of your choice. We stock the Bronze color, but other colors are available, call for more information.

Truth 27.32 project in window handle.

Truth Entrygard Dual Arm Operator. We would expect you to find 20755 on the linkage arm, which measures 3-3/4" overall length. Other common numbers we would expect to find are 31538, 31539, 30841, 30842, 30472, 30470, and 20755.  Call or email for quantity "Discount Codes".

To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.

3-3/4" link dimension, offset up. For offset down order Wi1520

Order Wi1510 if your link dimension is 4-7/16" stamped 20810.
Order Wi1515 if your link dimension is 2-7/8" stamped 20748.

Left hand shown.

PART # HAND
WI1516R RIGHT HAND
WI1516L LEFT HAND

Truth Entrygard Dual Arm Operator

The CRL PR90 is a Grade 1 door closer, the heaviest rating possible.  The template is the same as the LCN 4040 with the same features, latching speed, closing speed, back check and power adjustment from size 1 ADA compliant to size 6.

We offer the Standard Cylinder PR90 and also the Delayed Action PR92. Delayed Action will hold the door open for 15-20 seconds to allow handicap individuals to clear the opening before the door closes.

Single Hole Cam Handle

This handle is only available in the brushed bronze finish, the window handle is constructed of cast red bronze. We find this handle used with Fenestra Windows.

Right Hand S228RH
Left Hand S228LH

Sargent Door Closer Heavy Duty Compression Holder Arm

Forged Steel Arm 11-1/4" long, non handed, will work left or right for Parallel Armed Sargent Closers.  Permits 105 degree opening with built in compression stop and holder mechanism.

Sargent Part # 25-CPSH

Standard LCN 1460 series closer shipped with regular arm, a slim line plastic
cover, and self reaming and tapping screws. Non-sized (1-6) cylinder is adjustable for interior doors to 5’0” and exterior doors to 4’0”. Closer mounts hinge side, top jamb and parallel arm on either right or left
swinging doors.

We ship the 1461 Rw/PA

Dor-o-Matic 1790 Drive Bushing Set Screw, 10-16 3.8" UFPHMS SCREW

Doromatic part # SCREW.1150 or PB327

Door Pull 14

This handle has 5-1/2" centers on the mounting screws. And has a 2" diameter base. It features a 2-1/4" projection with a 1-1/2" clearance. Also known as a Door Handle or Door Grip. The handle ships with thru bolts and finish washers.

Finishes
