  1. Yale Exit Device Trim Spring Blue

    Yale Trim Spring Blue

    Also used on Corbin Russwin and Yale Lever trims. The Blue Spring is for RHR or LH doors. The spring has an outside diameter of 1-1/4".

    Yale Part # 60-7000-1224-999
    Corbin Russwin # 651F62

    G6070001224999
    $7.39
  2. Yale 7000 Exit Device Dogging Assembly

    Yale 7000 Exit Device Dogging Assembly

    Dogging assembly uses a 5/32" dog key

    Yale Part # 60-7000-406-999
    Sometimes call the 60-7000-0406-048

    G607000406
    $36.11
  3. Yale Exit Spring Trim Spring Red

    Yale Trim Spring Red

    Same part as the Corbin Russwin Lever Trim Spring. Used on Yale and Corbin Russwin LHR or RH Doors. The spring has an 1-1/4" diameter.

    Yale Part # 60-7000-1225-999
    Corbin Russwin # 651F61

    G6070001225999
    $7.39
  4. Yale 7110 Top Latch

    Yale 7110 Top Latch

    Yale 7110 Top Latch for the Non Fire Rated Yale 7000 Series Surface Vertical Rod.

    Yale Part # 60-7010-049-999

    G607010049999
    $123.12
  5. Yale 7000 Series Exit Device End Cap

    Yale 7000 Series End Cap

    Yale Part # ECK7

    Newer impact resistant end cap. Replaces all of the older version end caps for the Yale 7000 series.

    Shown in stainless steel.

    GECK7-yale
    As low as $108.34
  6. Yale 7100 Series Latch Assembly

    Yale 7100 Series Latch Assembly

    This latch assembly is used on non fire rated doors, meaning panic devices that you can not dog open with the allen key or key cylinder. Non fire rated doors are usually exterior doors.

    Yale Part # 60-7000-0419-048

    G6070000419048
    $150.70
  7. Yale 7100F Series Latch Assembly

    Yale 7100F Series Latch Assembly

    This Yale Latch Assembly is used on fire rated panic devices. A fire rated panic is a device were you can not lock the latch in the open position. It is used on doors were the engineers want the door to latch every time it closes to contain a fire.

    Yale Part # 60-7000-0425-048

    G6070000425048
    $162.51
  8. Yale 1500 Exit Device

    Yale 1500 Exit Device

    1500-36 For openings up to 36" (0.91m) wide.
    1500-48 For openings up to 48" (1.22m) wide.
    Strikes 799 Rim Strike (Single Doors)
    Stile Minimum Stile width: 4-1/2" (114mm)
    Hand Field Reversible

    1500EO-
    As low as $2,323.97
  9. Yale 2100 Exit Device

    Yale 2100 Exit Device

    Door Opening Width:
    -36 for 30" - 36" (76.2cm - 91.4cm) doors, Actual width is 31-3/4"
    -42 for 36" - 42" (91.4cm - 107cm) doors, Actual width is 37-3/4"
    -48 for 36-1/2" - 48" (92.7cm - 121.9cm) doors, Actual width is 43-3/4"
    Door Thickness: 1-3/4" (44mm) standard.
    Minimum Stile Width: 4-1/2" (114mm)
    Projection: 2-1/2" (64mm) active, 1-3/4" (44mm) depressed

    Aluminum is in stock, Dark Bronze has a 2 week lead time

    2100EO-
    As low as $386.58
  10. Yale 2000 Pull Trim

    • Through-bolted: 1-3/4" (44mm) door standard. For doors through 2-1/4" (54mm)
    • Plate Dimensions: 3-1/2" x 3-3/4" x 3/32" (89mm x 95mm x 3mm)
    • Finger Pull Dimensions: 3-1/2" x 6-3/4" x 1/8" (89mm x 171mm x 3mm)

    217F-
    As low as $62.80
  11. Yale 7100 Exit Device

    Yale 7100 Exit Device

    Door Opening Width:
    -36 for 30" - 36" (762 - 914mm) doors
    -48 for 36-1/2" - 48" (927 - 1219mm) doors
    Door Thickness: 1-3/4" (44mm) standard.
    Minimum Stile Width: 4-1/2" (114mm)
    Projection: 3-1/4" (83mm) active, 2-3/4" (70mm) dogged
    Latchbolt: 3/4" (19mm) deadlocking stainless steel Pullman-type
    Strike: 757 (panic),

    7100EO-
    As low as $1,263.97
  12. Yale 2100 Series Latch Assembly

    Yale 2100 Series Latch Assembly

    Latch assembly for the Yale 2100 Rim Panic Device.   Assembly base measures 7-3/4" high by 5-1/2" wide with a projection of 2-1/4".

    Yale Part # 60-2100-0010-048

    G6021000010048
    $123.12
  13. Yale 7250 Series Latch Assembly

    Yale 7250 Series Latch Assembly

    This latch assembly is used on the Yale 7250 Rim Device with the Square Bolt Latch.

    Yale Part #60-7250-0001-048

    G6072500001048
    $177.28
  14. Yale Strike 757

    Yale Strike 757

    Used on the Yale 7100, 7150, 7200 and the 2100 Exit Devices.  Furnished in a Black Finish.

    Yale Part # 757

    Y757
    $95.21
  15. Yale Strike 757F

    Yale Strike 757F

    Used on the Yale 7100F, 7150F, 7200ME and the 2100F Exit Devices.  Furnished in a Black Finish.

    Yale Part # 757F

    Y757F
    $95.21
  16. Yale Strike 759

    Yale Strike 759

    Used on the Yale 720X Exit Devices.  The Strike measures 2" wide by 3" high and 1/2" thick. Furnished in a Black Finish.

    Yale Part # 759

    G759
    $67.31
  17. Yale Strike 793

    Yale Strike 793

    Used on the Yale 7100 and 2100 Series Rim Exit Devices.  Optional strike for double door applications without a mullion.

    Yale Part # 793

    793
    $87.01
  18. Yale Strike 791

    Yale Strike 791

    Used on the Yale 7110, 7110F, 7120F, 7210MF, 7220MF, 2110F and 2110 Series Vertical Rod Exit Devices. And Corbin Russwin ED4400 and ED5400 Devices. The Top Strike no longer uses a Roller.  Used as the Top Strike.

    Yale Part # 791
    Corbin Russwin 650F548

    791
    $101.78
  19. Yale Strike 790

    Yale Strike 790

    Used on the Yale 7110, 7110F, 7120F, 7210MF, 7220MF, 2110F and 2110 Series Vertical Rod Exit Devices.  Used as the Bottom Strike.

    Yale Part # 790

    Y790
    $52.53
  20. Yale Strike 794

    Yale Strike 794

    Optional floor strike for fire openings using threshold or flush floor mounting.  For use with the 7100 and 2100 devices.  Used as the Bottom Strike.

    Yale Part # 794

    Y794
    $61.77
  21. Yale 1500 Dogging Shaft

    Yale 1500 Dogging Shaft

    Used on the Yale 1500 Rim and Surface Vertical Rod Devices.   This is the peice that the Dogging Key goes in to actuate the Dogging Piece.   The Dogging Shaft measures 1-3/8" long and approximately 5/16" diameter.  The hex is 5/32"

    Yale Part # 60-1500-1184

    G6015001184
    $9.92
  22. Yale 7100 Latch Cover

    Yale 7100 Latch Cover

    This latch cover is used on the Yale 7110 Surface Vertical Rod Device.  We stock these in Brushed Stainless Steel, other finishes will take longer.

    Yale Part # 60-7010-7040

    G6070107040-
    As low as $62.38
  23. Yale 1900 Traditional Door Closer

    The Yale Series 1900 Traditional Surface Closers represent a combination of traditional styling and modern closer features. All closer sizes are contained within a single size aluminum alloy shell. Templates for installing this closer are the same for all closer sizes.

    Yale Part # 1902/4

    Handing diagram

    1900
    As low as $1,432.15
  24. Yale 2300 Door Closer-Discontinued

    Yale 2300 Door Closer

    • Spring size 2, 3, 4, 5
    • Separate and independent valve for sweep speed and latch speed
    • Adjustable backcheck standard
    • Regular, top jamb, parallel mount
    • 5-year limited warranty
    • ANSI/BHMA A156.4 Grade 3

    3/4" x 9-1/16" hole spacing

    In April of 2023 Norton Yale have discontinued the 2300 and 9300.  The Norton 1600 will be sent in place of the 2300.   Same Hole Spacing, but adjustable spring tension.

    2300-
    As low as $160.47
  25. Yale 3300 Door Closer

    Yale 3300 Door Closer

    • Adjustable spring sizes 1 thru 6
    • Rack-and-pinion design
    • 1-1/4" (32mm) diameter piston
    • 5/8" (16mm) diameter pinion journals
    • Cast aluminum body
    • Standard, separate and independent, latch,
      sweep and backcheck intensity valves
    • Staked valves
    • Molded plastic cover standard

    This door closer replaces the older 3301BF closers. The new version is Barrier Free Complaint.
    3/4" x 12" hole spacing, the cylinder is sometimes cast 20-3301-1001 on the back of the cast aluminum
    cylinder.

    3300-
    As low as $322.56
