Truth
-
Truth Entrygard Window Operator 15.20
Truth Entrygard Dual Arm Operator. We would expect you to find 20755 on the bottom of the linkage arm, which measures 3-3/4" overall length. Other common numbers we would expect to find are 31538, 31539, 30841, 30842, 30472, 30470, and 20755. Call or email for quantity "Discount Codes".
To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.
3-3/4" link dimension, offset down. For offset up order Wi1516
Order Wi1510 if your link dimension is 4-7/16" stamped 20810.
Order Wi1515 if your link dimension is 2-7/8" stamped 20748.Left hand shown.
WI1520 -
Truth Entrygard Window Operator Offset Down 15.61
Truth Entrygard Dual Arm Operator. We would expect you to find 20810 or 20544 on the linkage arm, which measures 4-7/16" overall length. This is the most common size we find in use. Other common numbers we would expect to find are 31538, 31539, 30841, 30842, 30472, 30470, 20810, or 20544. Call or email for quantity "Discount Codes".
For offset up, order Wi1510.
To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.
Part # Hand
WI1561R Right Hand
WI1561L Left HandTruth Entrygard Dual Arm Operator
WI1561- -
Truth Entrygard Dyad Casement Window Operator 15.62
Truth 15.62 Dyad Casement Operator. The 15.62 is no longer manufactured, we can not get the Right Hand anymore, but have a decent supply of Left Hand's.
Same as the Wi1511, but linkage arm is off set up
Linkage arm stamped 20810A, gear stamped 31367L, base stamped 45108
Wi1562 -
Truth Entrygard Single Arm Window Operator 15.94
Common numbers found on the older version of this operator are 40575 for the right hand operator, and 40574 for the left hand operator
To determine hand of operator, if your sash lock (window lock), is on the left, you would use a left hand operator. And if your sash lock is on the right, you would order the right hand operator.
Left hand shown.
WI1594 -
-
-
Truth 22.17 Pivot Shoe Roto Awning Operator
Truth 22.17 Awning Window Operator
Surface mounted Truth Awning Window Operator. The arms span 13-1/4” from rivet to rivet. The mounting holes measure 6-7/8” on the outside screws center to center, and 6” center to center on the two inside mounting screws.
Truth Part # 22.17
Wi2217- -
Truth 22.21 Single Pull Awning Window Operator
Truth 22.21 Single Pull Awning Window Operator
The arms stretch 21-1/2" across in the closed position. The housing is front side mounted with 4 screws. The spacing on the outside screws are 7" on center, and 6" on the inter screws. We find the number 30895 or 30895A stamped on the arm.
The Wi11454 handle in matching color is included with the operator along with the Sash Hook Wi20008.
Wi2221- -
Truth 22.29 Awning Operator
Truth 22.29 Awning Operator
The Truth 22.29 is the rear mount awning operator, meaning the screws to mount it come in from the outside of the window frame. This usually means it is used on aluminum or vinyl clad windows. The arms measure 16-1/2" across in the closed position, or 16" elbow joint to elbow joint. The mounting screws are 7" on center. Common numbers found on the arms are 31254, 31255, and 30896. We only offer this operator in white.
Truth Part # 22.29.32.002
Wi2229 -
-
