General Partitions Pintle 5/8" Diameter For Steel Doors

Steel and white nylon construction. The Pintle is 5/8" diameter by 2-1/4" overall length with 5/16-18 threaded end. Also known as a Bathroom Stall Bottom Pintle 5/8" Medium Lift. Manufacture part # 98175.

Shipped with nut and lock washer.

Door Stop, Pilaster Mounted, 2-1/2" X 4-1/4", Stainless Steel.

Cast Stainless Steel construction. The door stop base is 3" wide by 1-1/4" high with a 2-5/16" hole spacing. The stop projects out 2-1/2" and has a rubber insert in it. This door stop is usually mounted on the pilaster or post. Also known as a Bathroom Stall Door Stop. Manufacture part # 4153.

Interior Steel Box Locker Door Pull, Hole spacing 2-3/16" between outer holes. Used November 1958 - Current, also known as 6719.

Ives Wall Mounted Door WS11X

• Constructed in heavy duty cast brass.
• Hexagon section on unit aids in fastening unit when expansion shield is used.
• Replaceable rubber bumpers features off-set shoulder and threaded shank
  that screws into body of unit.

Furnished with a threaded stud and expansion shield for
masonry type mounting. 2" diameter base by 3-3/4" projection.

Toilet Partition Bottom Hinge Assembly For 1" Door, 1-1/4" Pilaster Square Edge Cast Stainless Steel

Cast stainless steel construction. Set includes bottom hinge, pin and door insert. Also known as a Bathroom Toilet Stall Bottom Hinge Kit. Manufacture part #63033.

Shipped with mounting screws.

Toilet Partition Top Hinge Assembly For 1"Door,1-1/4"Pilaster Square Edge Cast Stainless Steel

Cast stainless steel construction. Set includes top hinge, pin and door insert. Also known as a Bathroom Toilet Stall Top Hinge Kit. Manufacture part #63043.

Shipped with mounting screws.

Norton CloserPlus Hold Open Arm

This heavy duty Parellel Arm can be used with the Norton 1600, 9300, 8000 and 7500 door closers. The knob on the main are locks and unlocks the arm to hold your door open.

Aluminum is in stock, Dark Bronze is 2-3 week lead time.
Norton Part # 6870T-8

International Door Closer 200 Series Overhead Door Closer

UL Listed
Built in positive back stop and hold open positions.
Two speed control valves: Closing and latching speeds controlled by separate regulating valves, fully adjustable after installation.
Positive centering for alignment and to hold door closed against any normal wind or draft.
Stable hydraulic door check fluid for any climatic operation and constant lubrication.

Hydraulic Cylinder only

2000-B-230 105 with Hold Open
2000-B-231 105 with No Hold Open
2000-B-232 90 with Hold Open
2000-B-233 90 with No Hold Open

Hadrian Door Kit for Ada Concealed Hinges. Standard hinges that butt up to the edge of the pilaster. Chrome plated parts include concealed hinges with toggle & screw, keeper bumper, ada turn latch, cover plate, pintle, nylon cam, double door pull handles, coat hook & bumper, top pin and all security screws included. For Hadrian partitions in steel or stainless steel partitions only. This product manufacture number is 601010, replaces 601000.

TH1110 Arch/Vista Wall Offset Pivots are used for both flush face frame installation and 1/8" recessed door applications. Pivots replace most major door manufactures. Suitable for aluminum doors weighing up to 125 pounds. These pivots are engineered and designed for durability, style and are easy to install. To order pivot: For LHRB door order RH pivot For RHRB door order LH pivot Specifications * 3/4" offset pivots for aluminum doors and frames * For flush door / frame and 1/8" recessed door applications * Weather resistant * Aluminum case construction * Vertical adjustment 1/8" * Full race ball bearing and design, provides smooth operation on bottom pivot door portion * No sag, entire weight of doors rests on floor mounted pivot portion * Completely temper proof, yet easily removable, replaceable in unlocked position * All pivots are handed- specify LH, RH * Finish: AL-Aluminum, DU-Duronotic

Ordering Online All Solid Plastic HDPE 10' Post & Panel Manufactured by Global Partitions. For other factory colors please call for pricing. All toilet partitions ship in 48-72 hours plus 2-4 days travel. All partition standard brackets included Floor & Ceiling Braced Post and Panel 1-3/4" square post up to 120" maximum with 55" high panel. This works great for entrances of bathrooms to add privacy when people walk in. See sizes below that are available for quick shipping. All sizes are ready for quick delivery. All kits included standard aluminum hardware.

Color Chart

Right hand or Left hand, 1972 to present.

actual size 15-3/4"x7-7/8"

Dorma part # 7414ARP689

3/4" X 10-1/4" Hole Spacing

Toilet Partition Bottom Hinge Assembly Chrome Plated For 1" Thick Door, 1-1/4" Pilaster Square Edge

Polished chrome plated zamac die cast construction. Kit includes Bottom Hinge, Pintle, Nylon Cam, and Bottom Hinge Door Insert. Bottom hinge measures 2-1/4" high by 1-1/4" wide with screw spacing of 1-1/2". Mounting lug projects out 1-1/4". Also known as a Bathroom Stall Bottom Hinge Kit. Manufacture part number 63710.

Screws are also included.

Global Partition Complete Solid Phenolic Free Standing Partitions, Overhead braced floor mounted stalls. Standard stalls 36"x60" depth (24" door), ADA stall 60"x60"depth (36" door). All Stainless Steel hardware included. Doors can be either in or out swing. Up to 8 standard stalls total or 7 standard and 1 ada stall. To have an ADA stall you must select 1 ADA 24x60, plus 1 standard stall for 1 complete 60x60 ada stall. To have an ADA stall & standard stall, you must select 2 standard stalls and 1 ADA stall 24x60. Color Thru is 10 days and Black Core ship in 5 Days, 2-4 days travel.
Global Solid Phenolic Color Chart

Comtec Toilet Partition 8" Wrap Around Hinge Set. Clear anodized aluminum for 1" panel and 1" door. Used by every Bathroom Toilet Stall manufacture on Solid Plastic Toilet Partitions Doors. Sometimes known as part numbers, 7978, 7988, 8974, 8984. These hinges are reversible by taking the 3 pieces apart and reconfiguring the opposite swing.

Interior Steel Equipment Locker Door Jamb for a Right handed locker. Facing the Locker the Hinges are on the right hand side. Made in the USA. Also known as 30705, 3501, 76009, is4414r, lin378.

Ordering online all solid plastic (HDPE) pilasters manufactured by global partitions, see color chart below. For other factory colors please call for pricing. All toilet partitions ship in 48-72 hours plus 2-4 days travel. Pilasters Include: floor mount hardware and Stainless Steel Shoes.Available for the following widths - 3, 4, 5, 6, 7, 8, 10, 12, 16, 18, 20, 22 and 24" x 82" ht for overheadbraced type.

Color Chart

Hadrian stainless steel between walls bathroom partitions floor mounted overhead braced stalls with a smooth surface. Standard stalls 36" x 60" depth (24" door), ADA stall 60" x 60" depth (36" door). Standard chrome plated alloy hardware included. Doors can be either in or out swing. Up to 8 standard stalls total or 7 standard and 1 ada stall. All toilet partitions ship in 48-72 hours plus 2-4 days travel. To have an ADA stall you must select 1 ADA 24x60, plus 1 standard stall for 1 complete 60x60 ada stall. To have an ADA stall & standard stall, you must select 2 standard stalls and 1 ADA stall 24x60.

Hadrian Stainless Steel Color Chart

Hadrian Instructions Stainless Steel

Bobrick SCRC solid phenolic partition between walls layout with overhead braced floor mounted stalls. Standard stalls 36" x 60" depth (24" door), ADA stall are 60" x 60" depth (36" door). All standard stainless steel hardware included with option of full stainless channels and piano hinges. Doors can be either in or out swing to choose from. Up to 8 standard stalls total or 7 standard and 1 ada stall. To have an ADA stall you must add Ada to add 24" to a standard stall of 36" to create 60" width, plus 1 standard stall for 1 complete 60x60 ada stall. To have an ADA stall & standard stall, you must select 2 standard stalls and add Ada 24". 1080 & 1090 series phenolic ship in 3-4 weeks plus travel time.

Bobrick Phenolic Color Chart

Bobrick 1080 Instructions

Bobrick 1090 Instructions

Complete Stainless Steel Between 2 Wall Partitions, Stainless Steel Overhead braced floor mounted stalls. Standard stalls 36"x 60"depth (24" door), ADA stall 60"x60"depth (36" door). Standard chrome plated alloy hardware included. Doors can be either in or out swing. Up to 8 standard stalls total or 7 standard and 1 ada stall. All toilet partitions ship in 48-72 hours plus 2-4 days travel. To have an ADA stall you must select 1 ADA 24x60, plus 1 standard stall for 1 complete 60x60 ada stall. To have an ADA stall & standard stall, you must select 2 standard stalls and 1 ADA stall 24x60. New Style slide latch with indicator in chrome plated version included. New Door style are Integrated for no gap off doors.

Global Stainless Steel Color Chart

Hadrian Door Kit includes Ada turn latches with hinges that wrap around the edge of the pilaster type. Cast stainless steel parts include wrap hinges, keeper bumper, ada turn latch, cover plate, pintle, nylon cam, double door pulls, top pin, coat hook with bumper and all security screws included. For Hadrian partitions in steel or stainless steel partitions only. This product manufacture number is 901010, replaces the 901000.

Glynn-Johnson 79 Series Overhead Door Holder Surface Mounted

Glynn-Johnson 70 and 79 series models are constructed primarily of Brass and 300 series Stainless Steel substrates, with several components fabricated of Steel treated to resist corrosion. Models in the 70 series utilize a 1/2"-diameter stainless steel bar, while the 79 series uses a 3/4" stainless steel bar. The bar is always provided in US32D. The spring, washer and nut are provided in a clear zinc finish.

GJ70-79 Catalogue

3" Kickdown Door Holder / Stop Zinc Plated Mickey

Zinc plated cold rolled steel,
Made in the USA
3" Arm Length

made by Grand Specialties

#6 X 3/4" Stainless Steel Sheet Metal Screws furnished.

Screw holes are slotted for adjustment

Extruded aluminum, with nylon brush

Fabricated from B & S 16 ga. (.050). Standard lengths are 36", 42" and 48". Custom capabilities include variations of all of the above parts including frame protectors and vertical rod protectors.
Custom sizes are available!

Screws included for mounting

Finishes

Metpar Partitions Top Pin 3/8" Diameter By 3-1/4" Long For Laminate Partitions

Threaded steel construction. The top pin measures 3/8" diameter by 3-1/4" long with 5/16-18 threads. It has a screw driver flat slot on one end. Also known as a Bathroom Stall Door Top Hinge Pin. Manufacture part # 98584.

Accurate Partitions Stainless Steel Ada Alcove Compartments. Stainless steel overhead braced floor mounted stalls are most commonly used. Alcove stall includes 36" door, 2 pilasters and panel. Doors can be either in or out swing. Standard chrome plated alloy hardware included. All toilet stalls ship in 48-72 hours plus 2-4 days travel. New Style slide latch with indicator in chrome plated version included. New Door style are Integrated for no gap off doors.

Accurate color chart

Accurate Instructions

Corbin Russwin Door Closer 2800 Regular Arm

Used on almost all of your Corbin Russwin door closers since the 1970's.

Part # 688F95

LCN Sentronic Roller

This LCN Sentronic Roller is used on all of the LCN Track Closers, and Sentronic Closers. Nylon wheel is 1-1/16" diameter by 3/8" thick. The shaft is has a 1/2" diameter by 1-1/8" long. LCN part # 4040SE-3034.

LCN Started using this Roller Assembly in December 2018.

Right hand or Left hand, 1972 to present. Actual size 13"x7-7/8". Also known as rs1136, lr40.

LCN Sentronic Door Closer 4040SE-3436 On/Off Switch

The LCN 4040SE On/Off Switch measures 1" by 1/2" and the button projects up 1" from the base. This component is usually mounted by two way foam tape to isolate if for undesirable shock.

LCN Part # 4040SE-3436

Complete Stainless Steel Alcove Partitions, Stainless Steel Overhead braced floor mounted stalls. Alcove stall includes 36" door, 2 pilasters and panel. Doors can be either in or out swing. Standard chrome plated alloy Hardware included. All toilet partitions ship in 48-72 hours plus 2-4 days travel. New Style slide latch with indicator in chrome plated version included. New Door style are Integrated for no gap off doors.

Global Stainless Steel Color Chart
