Search results for: 'bars latch part 9001'

Grab Bar L 54" x 42" ADA Accessible Concealed Snap on mounting,1-1/2" Diameter. Snap Flange (1-1/2" O.D) Smooth - Horizontal Grab Bar, 54" x 42". Snaps over mounting flange dimples to conceal screws and concealed mounting flange of 3-1⁄8″ O.D. diameter with 2 screw holes and 3 locking dimples; 1/8″ thick, type 304 stainless steel. Cover is type 304 stainless steel with a satin finish and 22 gauge, 3-3⁄16″ diameter. Known as 10-3857.

Lyon Metal Locker Double tier Lock Bar, Used Sept 2004 - Current. Comes with nano roller. Also known as RH679530.

Flush Metal Partitions Concealed Latch Housing

Zamac die cast construction. The latch body measures 3-3/8" deep by 1-15/16" high. The face plate is 3-1/4" high. The latch bolt is 11/32" diameter and has a travel of 7/16". Also known as a Flush Metal Bathroom Stall Concealed Latch Housing. Manufacture part # 6606. This part has a 1-1/4" diameter.

Hadrian's new style 7/15/19 partition Ada latch knob with set screw included. The latch is ADA compliant and meets barrier free codes.  They are constructed of Zamac die cast metal that is then chrome plated and polished. This part is used on Hadrian Partitions and will replace the old style concealed turn latch. The new manufacturer's part number is 601150, but also associates with old parts and replaces 601100, 601110, 601200. This new turn latch with set screw and cover will replace all standard or old Ada latches prior to 8/1/2019.

Aluminum Toilet Partition Slide Bolt Latch 3-1/2" Screws

Clear anodized aluminum construction. Base is 4-1/2" by 2" by 1/8" thick and projects out 1-5/8". Latch bolt is 1" wide by 3-1/8" long by 1/4" thick, and has a 1" throw. This Bathroom Stall Latch is usually used on Solid Plastic (HDPE) Toilet Partition's. Manufactures part # are 5054, 5058 and 650-8543. Also known as Toilet Partition Locks.

Shipped with mounting hardware.

A.W. Anderberg 201ST 4 bar window hinge, cadmium plated steel construction.

Usually found on light commercial or residential buildings with hopper windows. This hinge is being discontinued, and replaced by the 201SS Hinge, which has the same hole spacing, length, and stack height.

23/32" track width x 1/2" stack height.

If you have a casement window with a 16" track length, please see 222SS Egress Window Hinge.

Sold individually, these hinges are non handed, we recommend that you change both hinges when you are replacing them.

Von Duprin 9927 Top latch

Used on all the Von Durpin 9827 and 9927's. This latch updates your current latch if your device was installed before October 1998. If your device is newer that October 1998, then use the G050400. This is usually the problem if your bottom rod is dragging on the floor. Includes screws.

Von Duprin Part # 050091

Lyon Metal locker Black Nylon Lock Bar Retainer, Used September 2004 - Current. Also known as 6800.

Von Duprin 8827 Top Latch And Cover

The Von Duprin 8827 Top Latch and Cover in one convenient package. The package includes the Top Latch 050460, the Cover 050464, and cover screws and mount screws.

Von Duprin Part # 050466

Von Duprin Exit Device 47 Top Latch Kit 050492

This Von Duprin Concealed Top Latch is used on the 33A, 35A, 98 and 99 exit devices. The Latch Kit includes Latch, Mounting Brackets and all screws.

Von Duprin Part # 050492
Von Duprin Old Part # 109759

Grab Bar Installation Kit Exposed Dry Wall screws and toggles

Grab Bar Installation Kit Concealed Dry Wall screws and toggles.

Grab Bar Installation Kit Concealed Masonry Wall screw and anchor

General Partition Concealed Latch Knob & Cover

Zamac die cast construction with polished chrome plating. Outside diameter of the knob and cover are 1-5/8" with the inner ring diameter of 1-1/4". Also known as a Bathroom Stall Concealed Latch Cover and Knob Assembly. Manufacture part # 1390, 6140.

Hadrian's new style 7/15/19 Partition Ada Latch Knob includes the turn latch wit set screw and cover. The latch is ADA compliant and meets barrier free codes.  They are constructed of die cast stainless steel that is then a brushed finish. This part is used on Hadrian Partitions and will replace the old style concealed turn latch.  The new manufacturer's part number is 901150, but also associates with old parts and replaces 601100-700, 601110-700, 601200-700. This new turn latch with set screw and cover will replace all standard or old Ada latches prior to 8/1/2019.

Monarch Falcon 2130 Bottom Latch Strike

The Monarch Falcon 2130 Bottom Latch Strike is used on the 19-V, 24-V, 25-V and XX-V devices.  This strike usually fits into the threshold or is recessed into the floor.

Falcon Part # 2130

Sargent 8700 Old Style Top Latch-Before 11-2002

The Sargent 97-2434 Old Style Top Latch was used on the 8706, 8710, 8713, 8715, 8728, 8740, 8743, 8746,  8762, 8763, 8773, and 8774 Series Surface Vertical Rod Devices before November 11, 2002.

Sargent Part # 97-2434

Toilet Partition Surface Mounted Ada Slide Bolt Latch Inswing Latch & Keeper Stainless Steel

Stamped stainless steel construction. Latch is 2" wide by 2-7/8" tall. Latch bolt is 2-3/4" long by 13/16" wide by 1/8" thick and has a throw of 25/32". The keeper is 1-1/2" by 1-1/2" by .075" thick, and projects out 7/16". Commonly called a Bathroom Stall Latch for inswinging doors and Toilet Partition Locks. Manufacture part # 6409 and 6539.

Shipped with mounting screws.

Von Duprin 22, 33, 9927 Bottom latch.

Used to replace the bottom latch on the Von Duprin 2227, 3327A, and 9927 on devices shipped after October 1998.

Includes screws and sometimes the bracket

Von Duprin Part # 050401

Lyon metal Locker 36" Expanded Metal Lock Bar, Used March 1973 - Current. Also known as 676636.

Yale 7110 Top Latch

Yale 7110 Top Latch for the Non Fire Rated Yale 7000 Series Surface Vertical Rod.

Yale Part # 60-7010-049-999

Grab Bar Installation Kit Concealed 1" Panel 3"dia SS plate stud/nut

Yale 7250 Series Latch Assembly

This latch assembly is used on the Yale 7250 Rim Device with the Square Bolt Latch.

Yale Part #60-7250-0001-048

Note the Hub Position for this Assembly is the  7200

Push Bar Adjustable 450

Finishes:
US3/605 Polished brass
US4/606 Brushed brass
US10B/613 Dark bronze
US26/625 polished chrome
US26D/626 brushed chrome

Material: Brass
Material Size: 5/8" Rd Tube Adjustable up to 36"
Clearance: 1/2"
Projection: 1-1/8"
Fasteners: Surface Mount only

Lyon Metal Locker 60" Expanded Metal Lock Bar, Used in March 1973 - Current. Also known as 676660.

Double Door Latch for doors without a center post. Shown with out lock. Optional lock is just to prevent theft.

Doromatic Exit Device 1690/1990 Top Rod Latch Assy.

Used on the 1490, 1690 and 1990 Concealed Vertical Rod Devices

Doromatic Part # PB130, and also 4270101806

For use in 2' x 2' drop ceiling tile

Adams Rite G86 End Cap Parts Package 91-0943

The Von Duprin Latch Mounting Bracket 050546 is used on the 2227, 3327 and 9927.   It is for use with the 050400, 050401, 050091 and 050090 Surface Vertical Latches.

Von Duprin Part # 050546
Old Von Duprin Part # 971567

The Global Partitions stainless steel latch knob & cover with Screw, are a concealed latch that is held together by a screw.  They are constructed of cast stainless steel metal that is then brushed and polished. The manufacturer part number is 40-8263380. This was used up until October 2021.

Corbin Russwin ED4400/5400 Latch Cover

This latch cover is used on the Corbin Russwin ED4400/5400  Surface Vertical Rod Devices.  We stock these in Brushed Stainless Steel, other finishes will take longer.

Corbin Russwin Part # 650F64

Yale 7100 Series Latch Assembly

This latch assembly is used on non fire rated doors, meaning panic devices that you can not dog open with the allen key or key cylinder. Non fire rated doors are usually exterior doors.

Yale Part # 60-7000-0419-048

Note the position of the Hub for this Assembly is the 7100

Corbin Russwin ED5400 Bottom Latch, Corbin Russwin part # 650F58-8

Flush Metal Partition Concealed Ada Latch Knob Cover Chrome Plated

Zamac die cast construction with polished chrome plating. Outside diameter of the knob and cover are 1-5/8" with the inner ring diameter of 1-1/4". The ADA Barrier Free Lever is 2-9/16" long when measured from the all the way across the cover. The cover has an overall depth of 1-1/4". Also known as a Bathroom Stall Concealed ADA Latch Cover and Knob Assembly. Manufacture part # 6150
