Corbin Russwin ED4200S Latch Assembly

The Corbin Russwin ED4200S 681F618 Latch Assembly is used on the Narrow Stile SecureBolt Exit Device.  The difference between the ED5200S and ED4200S Latch Assembly is the location of the Hub.  Hub on the ED4200S Latch Assembly is located on the center line of the Assembly Mounting Screws.

Corbin Russwin Part # 651F618

The Hub Position on this Latch is the ED4200

Lyon Metal Locker Double tier Lock Bar, Used Sept 2004 - Current. Comes with nano roller. Also known as RH679530.

Need extra brackets for your Secuity Latches, you can order them here.  The are sold individually.  Constructed of welded steel and this then powder coated black.

Metpar Partitions Slide Bolt Latch with indicator Chrome plated Zamac die cast construction. The latch housing face plates measure 1-3/4" wide by 1-1/4" high. The latch thickness is 1-1/16". The latch bolt measures 3/4" by 3/16" with a 15/32" throw. Also known as a Metpar Bathroom Stall Concealed Latch. Manufacturer part # 4240, 13882. Metpar Toilet Partitions is the only manufacture that we know of that uses this latch.

Lyon Metal Locker Expanded Metal Lock Bar 72", Used March 1973 - Current. Also known as 676672.

Lyon Metal Locker single tier lock bar, 56-1/2" in length. Used Feb 1980 - Sept 1981.
3 Wire Springs included. Also known as 6775.

Chrome plated global slide latch with indicator and emergency access. Overall dimension 2-3/4" x 1-1/2" with 2-1/4" hole spacing. Used with new style doors 10/1/21 to current. Used with a 1 inch door. Security screws included. Manufactures part number 40-8513010.

Lyon Metal Locker Single Tier Lock Bar for 60" locker, length 53-1/4". Used September 2004 - Current.
Comes with 3 nano rollers. Also known as RH679460.

Doromatic 2090 Latchbolt spring. Pushes out the latch bolt.

Doromatic part # SPRING.104

Dor-o-Matic 1090/2090 Repair Parts Breakdown

Comtec Toilet Partitions Aluminum Slide Bolt Latch 3-1/2" Screws

Clear anodized aluminum construction. Base is 4-1/2" tall by 2" wide by 1/8" thick. Latch bolt is 3-1/8" long by 1" wide by 1/4" thick, and has a 1" throw. The latch bolt is 9/16" from the bottom of the base to the under side of the latch bolt. Also known as a Bathroom Stall Aluminum Slide Bolt Latch and Toilet Partition Locks. This latch is usually used on Solid Plastic (HDPE) Toilet Partitions. The manufacture part #'s are 4988, 650-4051, 650-8543 and HLSLA.

This latch ships with the mounting screws.

Von Duprin 55 Rim Latch Bolt Spring

Von Duprin 55 Rim Device Latch Bolt Spring

1-1/2" long x 3/8" diameter

Von Duprin part # 967502

Truth Nylon Tie Bar Guide 41157

This nylon guide is used when you have multiple sash locks on your window.  Inside the window, or sometimes on the surface these  nylon guides keep the connecting rods in place, so you only have to actuate one lock to lock multiple locks.

Truth Nylon Tie Bar Guide 45141

This nylon guide is used when you have multiple sash locks on your window.  Inside the window, or sometimes on the surface these  nylon guides keep the connecting rods in place, so you only have to actuate one lock to lock multiple locks.

Fiat Partitions Surface Slide Bolt Latch Chrome Plated

Zamac die cast construction, polished chrome finish. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the underside of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch and Toilet Partition Locks. Manufacture part # 5020.

Shipped with mounting screws.

Grab Bar 30" x 33" Ht ; ADA Accessible Compartments Require: 1-1/2" diameter with concealed snap on flange 30" x 33"ht.  2nd leg sticks out 5" x 12"ht. Right hand shown, left hand is on opposite side.

Dor-o-Matic 1790 Latch Assembly

Doromatic Part # LBOLT.105 or PB325

Accurate ADA Turn Latch & Cover

also known as 50-2511390, 50-2511370, 50-8511579, 50-8511510 complete. Chrome Plated. This latch assembly was used prior to January 2013. There is no exact replacement available.

This old style lock is discontinued 1/1/2022.
See link for replacement kits
https://www.robertbrooke.com/bathroom/partition-parts/conc-latch-fix-it-kit.html

Yale 2100 Series Latch Assembly

Latch assembly for the Yale 2100 Rim Panic Device.   Assembly base measures 7-3/4" high by 5-1/2" wide with a projection of 2-1/4".

Yale Part # 60-2100-0010-048

Sargent 8700 Top Latch Spring

The Sargent 8700 Top Latch Spring is used on most of the new and older style Sargent Panic Devices.   The springs measures 1-5/8" overall length.

Sargent Part # 97-0300

Lyon Metal Locker Single tier Lock Bar, Used Sept 2004 - Current. Comes with nano roller. Also known as RH679472.

General Partitions Slide Bolt Latch Chrome Plated

Zamac die cast construction, polished chrome finish. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5020.

Shipped with mounting screws.

Security Chase Mount Grab Bar fabricated with 18 gauge, 1-1/2" diameter tubing and flanges are 1/8" (3mm) thick stainless steel type 304 satin finish. The Closure Plate is 1/8" (3mm) thick and is welded the the bottom side of the grab bar. Closure plate is constructed of 12 gauge stainless steel. Unit has 3 rods welded to the back of the flange for wall mounting. Each flange is " in diameter Special Closure Plate is designed for Security and Anti-Ligature applications. Designed in mind for Behavioral Health and Detention Centers.

*** DISCOUNTINUED SIZES 36", 42" AND 48" IN 2024-25 ***

Flush Metal concealed turn latch knob and cover plate with set screw is the current style. This turn latch is one of a kind, under the cover plate and under the turn latch you will notice a diamond shape that are male - female. Only buy this if this is what you have exactly. Many of these parts look the same but are not and will not work unless this is what you have. Manufactures #143520. This part has a 1-3/8" diameter.

Penco Recess Locker Handle, stainless steel, also known as 60890H.
Used with a multi latching lock bar. Security screw included.

Global Partitions Surface Mounted Slide Bolt Latch Chrome Plated

Zamac die cast construction, polished chrome finish. Latch base is 4-1/2" high with 3-1/2" hole spacing. Latch bolt is 3-3/32" long by 1" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5050.

Shipped with mounting screws.

Used by accurate and global

Von Duprin 8827 Bottom Latch

Used on all Von Duprin 8827 non fire rated exits. Included mounting screws.

Von Duprin Part # 050461
Old part # 101751

American Sanitary Slide Bolt Latch Chrome Plated.

Zamac die cast construction, polished chrome finish. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5020.

Shipped with mounting screws.

Security Front Mount Grab Bar fabricated with 18 gauge, 1-1/2" diameter tubing and flanges are 1/8" (3mm) thick stainless steel type 304 satin finish. The Closure Plate is 1/8" (3mm) thick and is welded the the bottom side of the grab bar. Closure plate is constructed of 12 gauge stainless steel. Unit has 3 holes on each flange for exposed mounting. Each flange is " in diameter Special Closure Plate is designed for Security and Anti-Ligature applications. Designed in mind for Behavioral Health and Detention Centers.

Von Duprin 2227 Top latch

This latch is used on devices shipped before October 1998, see related products for the new style latch if your device is newer. This is usually the problem if your bottom rod is dragging on the floor. Includes screws.

Von Duprin Part # 050091

Von Duprin 8827-F Top Latch Kit 050462

This is the Top Latch Kit for the Von Duprin 8827-F. The 8827-F is the Fire Rated Surface Vertical Rod device usually used on interior doors to contain a fire. The Fire Rated version would not have dog screws to lock the device in the retracted postion.

Von Durpin Part # 050462
Old Part # 102676

Accurate Partitions Surface Mounted Slide Bolt Latch

Zamac die cast construction, polished chrome finish. Latch base is 4-1/2" high with 3-1/2" hole spacing. Latch bolt is 3-3/32" long by 1" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch and Toilet Partition Locks. Manufacture part # 5050.

Shipped with mounting screws.

Used by accurate and global

also known as 9G0136

Occupancy Indicator Latch Handle is constructed of cast stainless steel with a satin finish. Latch handle is designed for 3/4" Doors and is through mounted to the occupancy indicator. Features a 4-1/2" length handle that is tapered at one end to engage with keeper for locking. Features emergency unlatching access on front of indicator. Shipped with fasteners for mounting occupancy indicator to door and pilaster. Known as manufacturer part number 4993.

Monarch Falcon 3788 Strike Top Strike

The Monarch Falcon 3788 Top Latch Strike is used on the 19-V, 24-V, 25-V and XX-V devices.

Falcon Part # 3788

Von Duprin 8827-F Bottom Latch Kit 050463

This is the Bottom Latch Kit for the Von Duprin 8827-F. The 8827-F is the Fire Rated Surface Vertical Rod device usually used on interior doors to contain a fire. The Fire Rated version would not have dog screws to lock the device in the retracted postion.

Von Durpin Part # 050463
Old Part # 102681
