Surface Mounted Partition Slide Bolt Latch Chrome Plated 3/8" Bar To Door Clearance

Zamac die cast construction, polished chrome finish. Latch base is 4-1/2" high with 3-1/2" hole spacing. Latch bolt is 3-3/32" long by 1" wide by 3/16" thick. The latch bolt clearance is 5/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch and Toilet Partition Locks. Manufacture part # 5060.

Shipped with mounting screws.

Window Spring Latch

Transom window spring loaded window catch. White bronze casting, brushed nickel finish. This Window Spring Catch features a 1-7/16" hole spacing, and a 1/2" lock up dimension.

Cast S.S. Slide Bolt Latch 5/8" Bar To Door, 3-1/2" Between Screws. Cast stainless steel construction. Base is 4-1/2" tall with a hole spacing of 3-1/2" on center. Latch bolt is 3-3/32" long by 1" wide by 3/16" thick and has a throw of 15/16". The latch projects out 1-9/16". The distance from the back of the base to the underside of the latch bolt is 9/16". Also known as a Bathroom Stall Slide Latch and Toilet Partition Locks. Manufacture part #5053. Shipped with screws. Used by accurate and global.

The Doromatic Latch Screw PB17 is also known as the SCREW.1029.  The screw is a 10-32-1/4" with an undercut head.  This screw is used to hold the top and bottom latches on the door for the 1690 and 1990 series devices.

Yale 2100 Series Latch Assembly

Latch assembly for the Yale 2100 Rim Panic Device.   Assembly base measures 7-3/4" high by 5-1/2" wide with a projection of 2-1/4".

Yale Part # 60-2100-0010-048

Medart Bleacher Latch Nose, 2" hole spacing.

Doromatic Exit Device 1690/1990 Top Rod Latch Assy.

Used on the 1490, 1690 and 1990 Concealed Vertical Rod Devices

Doromatic Part # PB130, and also 4270101806

Von Duprin 55 Rim Latch Bolt Spring

Von Duprin 55 Rim Device Latch Bolt Spring

1-1/2" long x 3/8" diameter

Von Duprin part # 967502

ASI Alpaco Ada Indicator Latch is used by Accurate and Global Partitions. This European design is featured on the Alpaco Classic and Elegance Collection. Stainless steel construction make this indicator latch durable. These latches are created to be used on 3/4" thick material. Red and White indicator is used to show whether the stall is in use. Offers emergency access fom the outside with coin slot feature. Also known as 8273100.

Von Duprin 2227 Top latch

This latch is used on devices shipped before October 1998, see related products for the new style latch if your device is newer. This is usually the problem if your bottom rod is dragging on the floor. Includes screws.

Von Duprin Part # 050091

Chrome Plated Heavy Duty Partition Ada Throw Latch And Keeper

Polished chrome plated brass construction. Latch base is 2" x 2" and is 3/16" thick. The throw latch is 5-7/16" long by 1-1/4" by 7/32" thick. The keeper is 2" by 2" by 21-32" high. Meets ADA codes in most States. Also known as a Bathroom Stall Heavy Duty ADA Throw Latch and Keeper and Toilet Partition Locks. Manufacture part # 5701.

Shipped with mounting screws.

Center Hung Door Closer

• Available (NHO) non-hold open, or (SHO) selective
  hold open. Specify degree (90 or 105°)
• Standard top pivot: 340 included
• Cycolac cement case
• Separate independent valves for closing,
  latch and backcheck adjustments
• Built-in positive dead stop prevents door
  from swinging beyond desired opening
  degree
• Vertical and horizontal door adjustment
• Arm centering adjustment

Sargent 8700 Top Latch Spring

The Sargent 8700 Top Latch Spring is used on most of the new and older style Sargent Panic Devices.   The springs measures 1-5/8" overall length.

Sargent Part # 97-0300

Chrome Plated Partition Ada Throw Latch 3-1/2" Between Screws Latch Only

Chrome plated brass construction. Base is 4-1/2" wide by 1-1/2" high by 3/16" thick. Throw latch is 3-11/16" long by 3/4" x 3/16" thick. The latch projects from the stall door 1-3/8". Also known as a Bathroom Stall or Toilet Partiton Throw Latch. Manufacture part # 5151

Shipped with mounting screws.

Chrome plated global slide latch with indicator and emergency access. Overall dimension 2-3/4" x 1-1/2" with 2-1/4" hole spacing. Used with new style doors 10/1/21 to current. Used with a 1 inch door. Security screws included. Manufactures part number 40-8513010.

Metpar Partitions Concealed Latch Knob And Cover

Zamac die cast construction with polished chrome plating. Outside diameter of the knob and cover are 1-3/4" with the inner ring diameter of 1-7/32". Cover lugs project out 1-7/32" . The latch bolt is 11/32" diameter by 2-21/32" long, the square box has a height of 3/4". Also known as a Bathroom Stall Concealed Latch Cover and Knob Assembly. Manufacture part # 5090

All Steel Equipment Box Locker Latch only.

Knickerbocker Partitions Concealed Ada Latch Knob And Cover

Zamac die cast with polished chrome plating construction. The Cover has an outer diameter of 1-3/4" with a 1-11/32" inner ring diameter. The Knob has an outer diameter of 1-5/8" and and inner diameter of 1-11/32". ADA Lever is 3-3/4" long. Also known as a Bathroom Stall ADA Concealed Latch. Manufacturer part # 6170. Works with General partitions. Used with powder coated steel toilet partitions.

Occupancy Indicator Latch Handle is constructed of cast stainless steel with a satin finish. Latch handle is designed for 3/4" Doors and is through mounted to the occupancy indicator. Features a 4-1/2" length handle that is tapered at one end to engage with keeper for locking. Features emergency unlatching access on front of indicator. Shipped with fasteners for mounting occupancy indicator to door and pilaster. Known as manufacturer part number 4993.

Medart Bleacher Latch Bracket Right Hand. 2" Hole Spacing.

Concealed Latch Fix it Kits for Plastic Laminate Doors

For 1" Square edge for Plastic Laminate
All Hardware included

1690 Master Lock, Built-in lock for single point latch lockers - Wrap Around Latch Technology, automatic deadbolt locking, right-hand hinged door
For Single Point Lockers. Spring latch locks automatically.
RH Only
Master keys sold separately.We will need your master key number if adding to your existing system.
1-2 week lead time

Corbin Russwin ED5400 Bottom Latch, Corbin Russwin part # 650F58-8

Flush Metal concealed turn latch knob and cover plate with set screw is the current style. This turn latch is one of a kind, under the cover plate and under the turn latch you will notice a diamond shape that are male - female. Only buy this if this is what you have exactly. Many of these parts look the same but are not and will not work unless this is what you have. Manufactures #143520. This part has a 1-3/8" diameter.

The Von Duprin Latch Mounting Bracket 050546 is used on the 2227, 3327 and 9927.   It is for use with the 050400, 050401, 050091 and 050090 Surface Vertical Latches.

Von Duprin Part # 050546
Old Von Duprin Part # 971567

Aurora Steel Product Locker Latch Pin Only. Also known as 22003, 7811, 81013, au6606, lar216.

Monarch 19-24-25-XX Top Latch 588

Monarch 19-24-25-XX Top Latch 588 for non Fire Rated Doors.  This latch has a long history, the old number is 588, and the new number is 650389.  A non Fire Rated door is usually an exterior door, or a door that is not designed to contain the spread of fire.

Falcon Part # 650389

The heavy-duty 8900 Series non-handed surface applied closer
with adjustable spring power and backcheck positioning adjustment.
The 8900 has intensity adjustable hydraulic backcheck
that will take effect at approximately 65º. The 8900 has two
independent, noncritical adjustment valves to control sweep and
latch closing speeds. The backcheck positioning valve maintains
an effective backcheck range on parallel arm applications. The
8916 will be available with field adjustable spring power from size
1 to 6 for barrier-free requirements.

Chrome Plated Slide Bolt Latch 9/16" Bar To Door Clearance

Zamac die cast construction with polished chrome plating. Base is 3-3/8" high with 2-5/8" hole spacing. Latch bolt is 3-1/8" long by 7/8" wide by 3/16" thick with a 9/16" dimension from the door to the under side of the latch bolt. The latch projects out 1-1/2" when installed on the door. Also known as a Bathroom Toilet Stall Door Slide Latch and Toilet Partition Locks. Manufacture part # 6540.

Shipped with mounting screws.

This system is perfect for hotels, restaurants, churches and schools. It is easy to install and built to last.

Note: Hangers not included.

Coat Rack Information
Height: 12" (305mm)
Length: 2' to 50'+
Projection: 12 7/8" (327mm)
Slat Color Options: Light Oak Medium Oak Walnut
Racks can be made any size up to 50'.

Manufacturer will use slip joints so the rack can ship UPS/FEDEX.

Two person latch bar 1962-1970 18-1/16"length

Von Duprin 9927 Bottom latch

Replaces and updates all 9827 and 9927 bottom latches to the new style, if your device was installed before October 1998. If your device is newer then October 1998, then use the G050401. Mounting screws are included.

Includes screws and bracket

Von Duprin Part # 050090

Von Duprin 88 Latch Tail Springs

This is the spring that pushes the latch bolt out. Used on all Von Duprin 88 Rim Devices. The spring measures 2-5/8" long by 3/16" diameter.

Sold in packages of 2.

Von Duprin Part #050393

Flush Metal Toilet Partition Concealed Latch Knob And Cover

Zamac die cast construction with polished chrome plating. Outside diameter of the knob and cover are 1-5/8" with the inner ring diameter of 1-1/4". Also known as a Bathroom Stall Concealed Latch Cover and Knob Assembly. Manufacture part # 1390, 6140.
